Toroidal Voltage Single-Phase Transformer

Bochi Corporation
5Yrs
Toroidal Voltage Single-Phase Transformer thumbnail-1
Toroidal Voltage Single-Phase Transformer photo-1
US$ 5.00 - 15.00 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
BOCHI
Place of Origin:
Chongqing, China
Model Number:
BMEBK 5
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name BOCHI
Place of Origin Chongqing, China
Model Number BMEBK 5
Phase Single
Coil Number Autotransformer
Coil Structure Toroidal

Toroidal Voltage Single-Phase Transformer

Application:

  BK serials control transformer apply to 500V, 50-60 Hz circuit, Usually used as a machine control circuit or local lighting lamps and lamp power purposes



Structure:



  BK serials transformer is divided into shell type according to the structure, also can be divided into vertical according to the installation.

Toroidal Voltage Single-Phase Transformer



Installation environment:



 1,The environment temperature is between-5℃ and 40℃, the highest monthly temperature is not exceed +30℃.
 2,Altitude is not exceed 1000m.
 3,Humidity is not exceed 50% when the temperature is +40℃,At lower temperatures can have compared with the relative humidity, the wettest month of the average maximum humidity is 90%, while the monthly average minimum temperature is + 25 ℃, and taking into account temperature changes in the surface of condensation .



Specification:



Type

Outside diameter

Installation hole

Mounting holes
K × J

Bmax

Dmax

Emax

A

C

BK-50

86

95

93

70±0.4

50±3

5 × 12

BK-100

100

107

113

85±0.4

60±2.5

6 × 12

BK-150

100

107

113

85±0.4

66±2.5

6 × 12

BK-250

160

110

137

100±0.4

80±3

9 × 11.5

BK-300

160

125

137

100±0.4

80±3

9 × 11.5

BK-400

160

143

137

100±0.4

92±3

9 × 11.5

BK-500

160

143

137

100±0.4

92±3

9 × 11.5

BK-700

160

160

137

100±0.4

102±3

9 × 11.5

BK-1000

160

180

137

150±0.4

100±3.5

9 × 11.5

BK-1500

160

240

137

160±0.4

132±3.5

9 × 11.5

BK-2000

184

270

137

160±0.4

132±3.5

9 × 11.5







Product picture:

Toroidal Voltage Single-Phase TransformerToroidal Voltage Single-Phase Transformer
