High Quality Dimmer LED

High Quality Dimmer LED photo-1
US$ 5.00 - 15.00 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Brand Name:
BOCHI
Place of Origin:
Chongqing, China
Model Number:
ETH-8000
Payment & Shipping
Payment Methods:
Port of Shipment:
China port
Delivery Detail:
Delivery time depends on order quantity.
Brand Name BOCHI
Place of Origin Chongqing, China
Model Number ETH-8000
Type Remote Control
Voltage 220V
Max. Load Power High Quality Dimmer LED

High Quality Dimmer LED





Application:



  ETH-9000 is a dedicated multi-functional LED lighting dimmers, using the most advanced PWM (Pulse Width Modulation) digital dimming technology, output 0                                                                             to10V PWM signal can be a perfect match for PWM dimming power, 0 10V power supply and dimming SCR dimming power, and to achieve long-distance wireless remote control dimmer.

                                                           Suitable for controlling a variety of led lamps as the light source, such as: point light, flexible light strip, wall washer lamp, glass curtain wall lights, LED modules. With low prices, easy wiring, simple to use and so on. Through wireless remote control brightness adjustment, floodlight range 0-100% dimming soft no flicker.



Technical Parameter:

 1. Supply voltage: AC90-240V 50HZ / 60Hz

2. Output circuit: 2-way (PWM or 0-10V + AC output)

3. dimming: PWM dimming or 0-10V dimming + trailing edge phase dimmer

4. Compatible market above 95% PWM signal dimming power supply, 0-10V dimming signal power, SCR dimming power

5. 0-10V PWM Dimming Current: 300mA

6. AC Maximum output current: 1A

7. AC output effective power: 200W (reprovision power expander, unlimited expansion of output power)

8. RF frequency: 433MHZ

9. Switch Type: RF wireless remote control



Outside diamention and weight:

 1. Controller Dimensions: L123 * W78.5 * H33mm

2. Remote control size: L87mm * W63mm * H12mm

3. Packing size: L130 * W85 * H55

3. Net weight: 200g

4. Gross Weight: 280g



High Quality Dimmer LEDHigh Quality Dimmer LEDHigh Quality Dimmer LEDHigh Quality Dimmer LEDHigh Quality Dimmer LED
