Home > Products > Marine Electrical Equipment > DC Moibale Power Source/Power Supply
DC Moibale Power Source/Power Supply
- 1000 Set / Sets per Month
- China port
- T/T Credit Card
Product Details
Brand Name: | BOCHI | Place of Origin: | Chongqing, China | Model Number: | WYJDC 1 |
Output Current: | 0-A can be adjusted | ||||
Output Frequency: | 50/60Hz | Input Voltage: | 220V |
Packaging Details
carton
Product Description
DC Moible Power Source/Power Supply
Application:
Applied to teaching experiments, research, testing and aging of electronic production lines, communications equipment maintenance, and other areas that require DC power supply.
Products characteristic:
1.Specification range:Output voltage 0~1000V, output current 0~200A, output power 0~20KW can
be adjusted
2.Constant voltage adn current:Voltage and current from 0 to retaed number constant adjust, constant voltage and current change automatically.
3.Overvoltage protection: the number of voltage protection number continuously adjustable in
0~120%, Trip protection happens when output voltage exceed voltage protection value.
4.Short circuit protection: Under no circumstances allow long-term short circuit or short boot.
5.Intelligent: connet with PLC,to make remote control intelligent stablized power supply.
6.High adaptability.
Technical Parameter:
Input voltage | AC220V±10%, AC380V±10% |
Input frequency | 50Hz±10% |
Output voltage | 0~1000V |
Output current | 0~200A |
Output power | 0~20KW |
Working term | Stable state automatically change |
Ouput voltage and current | 0~rated value |
Constant voltage indicate | CV, green LED |
Constant current indicate | CC, red LED |
Working term | Long-term work at full capacity |
Compressive strength | 1500V 60S |
Working temperature | -20℃~+40℃ |
Relative humidity | 10%-90% |
Product Model:
Output current | 0~15V | 0~30V | |||||||||
Type / power | Size (mm) | Type / power | Size (mm) | ||||||||
0~80A | WYJ-1580 | 1200W | 350*500*675 | WYJ-3080 | 2400W | 350*500*675 | |||||
0~100A | WYJ-15100 | 1500W | 350*500*675 | WYJ-30100 | 3000W | 350*500*675 | |||||
0~150A | WYJ-15150 | 2250W | 350*500*675 | WYJ-30150 | 4500W | 350*500*675 | |||||
0~200A | WYJ-15200 | 3000W | 403*630*955 | WYJ-30200 | 6000W | 403*630*955 | |||||
Output current | 0~50V | 0~60V | |||||||||
Type / power | Size (mm) | Type / power | Size (mm) | ||||||||
0~80A | WYJ-5080 | 4000W | 350*500*675 | WYJ-6080 | 4800W | 350*500*675 | |||||
0~100A | WYJ-50100 | 5000W | 350*500*675 | WYJ-60100 | 6000W | 403*630*955 | |||||
0~150A | WYJ-50150 | 7500W | 403*630*955 | WYJ-60150 | 9000W | 403*630*955 | |||||
0~200A | WYJ-50200 | 10000W | 403*630*955 | WYJ-60200 | 120000W | 403*630*955 | |||||
Output current | 0~100V | 0~120V | |||||||||
Type / power | Size (mm) | Type / power | Size (mm) | ||||||||
0~20A | WYJ-10020 | 2000W | 350*500*675 | WYJ-12020 | 2400W | 350*500*675 | |||||
0~30A | WYJ-10030 | 3000W | 350*500*675 | WYJ-12030 | 3600W | 350*500*675 | |||||
0~50A | WYJ-10050 | 5000W | 350*500*675 | WYJ-12050 | 6000W | 403*630*955 | |||||
0~80A | WYJ-10080 | 8000W | 403*630*955 | WYJ-12080 | 9600W | 403*630*955 | |||||
0~100A | WYJ-100100 | 10000W | 403*630*955 | WYJ-120100 | 12000W | 403*630*955 | |||||
0~150A | WYJ-100150 | 15000W | 403*630*955 | WYJ-120150 | 18000W | 403*630*955 | |||||
Output current | 0~150V | 0~200V | |||||||||
Type / power | Size (mm) | Type / power | Size (mm) | ||||||||
0~20A | WYJ-15020 | 3000W | 350*500*675 | WYJ-20020 | 4000W | 350*500*675 | |||||
0~30A | WYJ-15030 | 4500W | 350*500*675 | WYJ-20030 | 6000W | 350*500*675 | |||||
0~50A | WYJ-15050 | 7500W | 403*630*955 | WYJ-20050 | 10000W | 403*630*955 | |||||
0~80A | WYJ-15080 | 12000W | 403*630*955 | WYJ-20080 | 16000W | 403*630*955 |
Packaging:
With the aim of "to establish a close strategic partnership and develop together with customers",
we will work whole-heartedly to improve our products and service
BOCHI can provide CCS, ABS, DNV, GL, LR, RINA, BV, NK, KR, RS...etc.
We can satisfy all the customers requirments.
Factory:
If u have any requirements or enquiry, pls contact me without hesitation.
