Help CenterBrake Drum (disc) Lathe T8465
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Horizontal
Condition:
New
CNC or Not:
CNC
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
15 days
Related Products
-
Brake Drum Disc Lathe Machine (C9335)NegotiableMOQ: 1 Piece -
Brake Drum Disc Lathe Machine (C9372)NegotiableMOQ: 1 Piece
-
Brake Drum Disc Lathe Machine (C9350C)NegotiableMOQ: 1 Piece
-
Brake Disc Lathe Model Kc500NegotiableMOQ: 1 Piece
-
High Quality Auto Brake Cutting Drum Disc Lathe for Brake Disc T8470NegotiableMOQ: 1 Piece
Type
Horizontal
Condition
New
CNC or Not
CNC
Specifications
High cost performance
2. Easy operation
3. Ideal for repair brake drum/disc of automobiles.
Features:
1. Brake drum lathe T8465 is a kind of lathe. It can fulfill the reparation of the brake drum, disc and shoe of automobiles from minicar to medium trucks.
2. The brake drum/shoe can be cut on the first Spindle and the brake disc can be cut on the second Spindle.
3. This lathe has higher rigidity, accurate workpiece positioning and is easy to operate.
4. If you adopt this brake drum lathe, there is no doubt for your enterprise to set up higher reputation due to better process quality and lower your process cost.
| Item | T8435 | T8445 | T8465 | |
| Brake drum diameter | mm | 180-350 | 180-450 | 180-650 |
| Brake disc diameter | mm | ≤350 | ≤400 | ≤500 |
| Working travel | mm | 150 | 170 | 250 |
| Spindle rotation speed | rpm | 80,120 | 30,52,85 | 30,52,85 |
| Feeding capacity | mm/r | 0.16 | 0.16 | 0.16 |
| Main motor | Kw | 0.55 | 1.1 | 1.1 |
| Overall dimension(L*W*H) | mm | 544*627*640 | 690*890*880 | 800*875*1050 |
| Net weight | Kg | 240 | 320 | 580 |
