High Precison & Heavy Duty Industrial Lathe (CD6241)

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Business Type:

Manufacturer

Year Established:

2015

Overseas Office:

Yes

Zaozhuang Make Machinery Co.,ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

High Precison & Heavy Duty Industrial Lathe
Model	CD6241
Max.swing over bed	Φ410mm(16")
Max.swing over croos slide	Φ255mm(10")
Max.swing over gap	Φ580(23")
Center height	205mm(8")
Distance between centers	100mm(40")/1500mm(60")
Width of bed	250mm(10")
Max.section of tool	20mm20mmm(3/4"3/4")
Max.travel of cross slide	210mm(8 1/2"）
Max.travel of compound rese	140mm(5 1/2")
Spinlde bore	Φ52mm(2")
Spindle nose	D1-6
Taper of spindle speed	MT#6
Range of spindle speed	16 changes 45-1800r/min
Leadscrew pitch	28mm*6mm/4 T.P.I.
Range of metric longitudinal feeds	0.05-1.7mm/rev(17 Nos)
Range of inch longitudinal feeds	0.002"-0.067"/rev(17 Nos)
Range of metric cross feeds	0.025"-0.85/rev(17 Nos)
Range of inch cross feeds	0.001"-0.0335"/rev(17 Nos)
Range of metric threads	0.2-14mm(No.40)
Range of inch threads	2-72 T.P.I(No.46)
Range of diametrical pitch	8-44 D.P.(22 Nos)
Range of module pitches	0.3-3.5 M.P.(19 Nos)
Dia.of tailstock sleeve	50mm(3")
Travel of tailstock sleeve	120mm(4-3/5")
Morce taper of tailstock sleeve	MT#4
Power of main motor	2.2/3.3kw(optional 3/4.5kw)
Power of coolant pump	4P,3PH,91W
Overall diamension(LWH)	19408501321mm
Packing size(LWH)	20308201620/25308901621mm
N.W./G.W.	1550/1760kg 1950/2211kg
