Technical Parameters	UNIT	M1024AHR
piece to be Ground(L*W)	mm	520*250
Max. grinding length	mm	540
Max. grinding width	mm	260
Distance from table surface to spindle center	mm	450
Slider way		Double V rail
load	kg	200
Table size(L*W)	mm	520*250
Number of T-slot	mm*n	14*1
Speed of working table	m/min	18
Cross feed on hanewheel	mm	0.02/graduation 2.5/revolution
Vertical feed on handwheel	mm	0.001/0.01/0.1graduation 0.1/1/10/revolution
Wheel size (diawidthbore)	mm	2002031.75
Spindle speeds	rpm	2800
The total power of electtic motor	kw	4
Spindle motor	kw	1.5
The machined surface of the base of parallelism	mm	300/0.005
Surface roughness	μm	Ra0.32
Working pressure	mpa	3
Max.capacity	L/min	18
Minimun of numerical	L/min	80
Coolant pump	kw	0.04
Machine size(LWH)	mm	168012201720
Packing size(LWH)	mm	175012501960
Net,Cross	T	1.1,1.2
