Cord anchorage pull testing machine/tension testing equipment /thrust testing apparatus for solar panel
Testing standard
It's conform IEC61215-2:2016 testing standard
Purpose
It’s to determine that the terminations, the attachment of the terminations, and the attachment of the cables to the body of the module will withstand stresses that are likely to be applied during normal assembly or handling operations, test in 4.14.2 (MQT14.1) and test in 4.14.3 (MQT 14.2) are to be performed .
The Main Technical Specifications
| Drive ways | Use motor offer the drive power |
The mass of weights |
30N, 42N,55N,70N,80N,90N,100N,115N |
Pull cycle |
1s |
Times |
54 times (can set) |
Displacement |
Manual measurement |
| Electricity | 1 phase 220V 50HZ |
Testing Procedure
1. The unloaded cable shall be marked so that any displacement relative to the gland can be easily detected
2. The cable is pulled for duration of 1s, 50times, without jerks in the direction of the axis with the relevant force
3. At the end of the pull test, remove the force from the test mandrel, then measure the displacement of the cable at the outlet of the junction box
