Home > Products > PV Module Tester > Salt Spray Testing Machine /PV Module Testing Chamber/Salt Mist Testing Machine for pv Module With IEC61701 Testing
Salt Spray Testing Machine /PV Module Testing Chamber/Salt Mist Testing Machine for pv Module With IEC61701 Testing
US$ 8,000 - 23,000
/ Set
1 Set(Min. Order)
- shenzhen
- T/T Credit Card
You May Like
-
Photovoltaic Conduit Bend Testing Machine/guide Tube Winding Testing Equipment /testing Apparatus With IEC Standard
-
IEC61215 Standard Solar Panel UV Preconditioning Testing Machine/UV Preconditioning Test Chamber/solar Panel Testing Machine
-
Conduit Bending Testing Machine/Solar Panel Testing Machine/PV Module Testing Machine With IEC61730
-
IEC61215-2 Solar Panel PV Module Cord Anchorage Pull Testing Machine /pv Module Testing Equipment
-
Cord Anchorage Pull Testing Machine/tension Testing Equipment /thrust Testing Apparatus for Solar Panel
-
PV Module Hail Pound Testing Machine/testing Apparatus/testing Equipment
Product Details
| Brand Name | HOTOTECH | Place of Origin | China | |
| Model Number | HTPV-1IJ | Power | Electronic |
Product Description
Company logo
Product Description
Salt Spray Testing Machine/PV Module testing chamber/Salt mist testing machine for pv module with IEC61701 testing
Standard
It's conform IEC61701-2011 testing standard requirement
Purpose
The test is used the anti-erosion quality of the surface of all materials after the rust -proof of painting, coating, electroplating, anoding and rust-proof of the greasing
The Main Techincal specifications
| Product Name | Salt spray testing machine/pv module testing chamber/salt mist testing machine for pv module with IEC61701 testing |
| Testing standard | IEC61701 test |
| The maximum module size | 2000×1000mm |
| Testing module quantity | 2 PCS |
| Temperature range | RT-55℃ (55℃ used for module drying) |
| The relative umidity | 30%~98% |
| Relative humidity deviation | +2%, -3% |
| Temperatuare uniformity | ≤±2% |
| Temperature fluctuation | ≤±1% |
| Salt deviation | ≤±1% |
| Spray quantity | 1-2ml/80cm3 |
| PH range | 6.5~7.2 |
| Shell material | Resistance corrosion stainless steel |
