China Manufacturer PV module UV preconditioning testing chamber /UV tester /UV chamber
Standard
UV preconditioning testing chamber satisfy IEC61215 , IEC61646 ,IEC61345 standard etc
Purpose
Main specific PV module when expose to the ultraviolet irradiating environment,to check the
resistance ultraviolet irradiating ability test ,and evaluate save polymer material and protect layer etc material resistance ultraviolet irradiating performance . Main use PV industry and solar industry
necessary test equipment , use test PV component , main is monocrystalline silicon components ,the ground uses crystalline silicon photovolatic modules ,the ground sues thin film photovoltaic modules and a series of photovoltaic modules for UV accelerated weathering test can represent the damage
produced by the sun .
The Main Technical specifications
| Product Name | China Manufacturer PV module UV preconditioning testing chamber /UV tester /UV chamber |
| Testing standard | IEC61215,IEC61646 |
| Testing sample size | 2000mm×2000mm |
| Testing sample quantity | 2PCS |
| Light source | Metal halid lamp |
| Lamp life | 1000 hours |
| Irradiation strength wavelength | 280nm~385nm |
| Irradiance uniformity | Be better than ±15% |
| UVA wavelength | 320nm~385nm |
| UVB wavelength | 280~320nm |
| Module surface temperature | 60℃±5℃ |
| Temperature resolution | 0.1℃ |
| Light ways | Upper light ,module test plane vertical light source |
| Monitor ways | Real-time monitor UVA and UVA strength |
| Control ways | Touch screen control |
| Electricity | 380V 50HZ |
Product Images show
1.High quality and best after-sell service
2.100% quality inspection before delivery
3.Managment Innovate
4.Strong R & D team
5.Can handle customers's feedback problems and doubt timely
6.Our testing machine have one year Warranty time
