Solar panel UV preconditioning tester/Solar panel Testing chamber/Solar panel testing machine
Standard
The UV preconditioning testing chamber satisfy IEC61215 , IEC61646 ,IEC61345 standard etc
Purpose
It's to precondition the module with ultra-violet (UV) radiation before the thermal cycle/humidity freeze tests to identify those materials and adhesive bonds that are sussceptible to UV degradation
The Main Technical Specifications
| Product Name | Solar panel UV preconditioning tester/Solar panel testing chamber/solar panel testing machine |
| Testing standard | IEC61215, IEC61646 etc |
| Raw material | can completely obstruct ultraviolet rays, tightness, good thermal insulation's high quality materials |
| Irradiation are | 2000mm×2000mm(custimized) |
| Testing module quantity | 2PCS |
| Light source | Metal halid lamp |
| Lamp life | about 1000hours |
| Irradiation strength wavelength | 280nm~385nm |
| Irradiance uniformity | be better than ±15% |
| Monitor | Real-time monitor and show UVA and UVB strength |
| UVA wavelength | 320nm~385nm |
| UVA wavelength | 280~320nm |
| Module surface temperature | 60℃±5℃ |
| Temperature resolution | 0.1℃ |
| Ozone | almost no ozone is produced |
| Light ways | upper light , module teset plane vertical light source |
| Control and display ways | Touch screen operate and real-time monitor |
| Electricity | 380V 60HZ |
1.High quality and best after-sell service
2.100% quality inspection before delivery
3.Managment Innovate
4.Strong R & D team
5.Can handle customers's feedback problems and doubt timely
6.Our testing machine have one year Warranty time
FAQ
Q: Are your company a trading or factory ?
A: Factory +Trade (integration) , 8 years focusing n test machines field and exporting experience , OEM also acceptance for us
Q: After an order is placed , when to deliver
A: Generaly about 30 work days
Q: Do you have any certificate about your factory ?
A: We are already got SGS , ISO 9001 and some testing machine's patent certificate
Q: What about the Warranty with after-sales service ?
A : We have one year warranty time , when the testing machine have problems and the customer notice us
We received the customer problems feedback ,we will reply and help customer to solve the problem at first time
Q: How about your testing machine's data accurate ?
A: About our testing machine's data accrate, customers can be assured, because many government's lab by our factory help to plan and established
