Home > Products > PV Module Tester > PV module Salt Spray Testing machine/Salt fog chamber corrosion tester equipment/salt spray test chamber
PV module Salt Spray Testing machine/Salt fog chamber corrosion tester equipment/salt spray test chamber
USD $900 - $1,000
/ Set
1 Set(Min.Order)
- 50 Set / Sets per Month
- ShenZhen YanTian
- T/T Credit Card
You May Like
-
Solar panel Salt mist / slat fog/salt atmosphere environment testing chamber
-
Salt Spray flow mixing gas corrosion tester /testing chamber/testing equipment for solar panel
-
Salt Spray flow mixing gas corrosion testing machine for solar panel
-
IEC 61215 standard Salt mist aging Testing Machine /testing chamber for solar panel and pv module
-
China Manufacturer PV module UV preconditioning testing chamber /UV tester /UV chamber
-
Solar panel ultraviolet pretreatment tester/UV aging Testing machine/Solar panel testing equipment with IEC61215-2:2016
Product Details
| Brand Name | HOTOTECH | Place of Origin | Guangdong, China | |
| Model Number | HTPV-12AB | Power | Electronic |
Product Description
Company logo
Product Description
PV module Salt Spray Testing machine/Salt fog chamber corrosion tester equipment/salt spray test chamber
Standard
It's conform IEC61701 testing standard
Purpose
The testing is used to test the anti-erosion quality of the surface of all materials after the rust-proof of painting, coating, electroplating, anoding and rust -proof of greasing
The Main Technical specifications
| Product Name | PV Module salt spray testing machine/Salt fog chamber corrosion tester equipment/salt spray test chamber |
| Testing standard | IEC61701 |
| The maximum module size | 2000×2000mm |
| Testing module quantity | 2 PCS |
| Temperature range | RT-55℃ (55℃ used for module drying) |
| The relative humidity | 30%~98% |
| Relative humidity deviation | +2%, -3% |
| Temperature uniformity | ≤2℃ |
| Temperature fluctuation | ≤±1% |
| Salt deviation | ≤±1% |
| Spray quantity | 1~2ml/80cm3 |
| PH range | 6.5~7.2 |
| Shell material | Resistance corrosion stainless steel |
| Electricity | 380V 60HZ |
Products images show
