Home > Products > IEC test Probes > knife probe 2 UL 749 accessibility iec test probe
knife probe 2 UL 749 accessibility iec test probe
- 100 Piece / Pieces per Month
- shenzhen
- T/T Credit Card
Product Details
Brand Name: | bnd | Place of Origin: | Guangdong, China | Model Number: | ul749 |
Packaging Details
Safety Aluminum foil box for ul749 knife probe
Product Description
knife probe 2 UL 749 accessibility iec test probe
Product details:
It conforms to standard requirement of UL749 Fig 3(SB0504A). It is a dedicated instrument for household dishwasher protective testing. It is an essential test instrument to detect the safety performance of the relevant home appliance products. The handle is made of Nylon and the probe is made of stainless steel.
BONAD offers a wide range of testing probes which designed and manufactured according to IEC,EN,UL,GB,ASTM and others. These probes are intended to verify the protection of persons against access to hazardous parts of home electronics and appliances,toys,tools and a hose of other products. These probes simulate human fingers,tools and other items that would be hazardous to come in contact with certain parts of products
Parameter:
1,Probe l Length :127mm(5INCHES)
2,Probe Thickness:0.81mm(0.032INCH)
3,Standard:UL749 Fig3
Note
Test probe is precision stainless steel products, please use of gently and pay attention to maintenance
IEC61032
Product picture | Reference Standard | Specification |
Test Probe 31 | IEC61032 | Rod Diameter: 25±0.2 mm Rod Length: 80±0.2 mm Plate Former Diameter(Min): 60±0.2 mm Plate Back Diameter (Max): 110±0.2 mm Total Length: 150±0.2 mm |
Test Probe 32 | IEC61032 | Dam-board Diameter:50mm Rod Diameter:25mm |
Test Probe 41 | IEC61032 | Test Rod Diameter: 30mm Rigid Finger Length:80mm Handle Diameter:50mm Handle Length:80mm |
Test Probe43 | IEC61032 | Probe Thickness: 5±0.05 mm Probe width: 50±15 mm Probe Length: 80±0.2 mm Reference standards : IEC610 32-1997 Bar Wide:50mm Thickness:5mm |
