Home > Products > Test Chamber > Mini High Temperature Chamber
Mini High Temperature Chamber
US$ 3,500 - 8,500
/ Set
1 Set(Min. Order)
- Shenzhen
- T/T Credit Card
You May Like
-
Model BND-TYF Solar Radiation Test Chamber for Aging Test
-
High Temperature Pressure Chamber for Boiling Steaming Test
-
Integrated Test Chamber for Temperature Humidity And Vibration Test
-
Series BND-THLP Low Pressure Integrated Environmental Chamber
-
Burning Flammability Test Equipment for Automotive Interior System
-
Model BND-SPR Horizontal and Vertical Burning Tester
Product Details
| Brand Name | BONAD | Place of Origin | Guangdong, China | |
| Model Number | BND-MC | Power | Electronic | |
Wooden Box
Product Description
Mini High Temperature Chamber
Bonad makes high temperature chambers with different sizes. Just choose the perfect one for your products!
Product Show
Mini High Temperature Chamber
Detailed Information
Mini High Temperature Chamber Parameters:
| Mini high temperature(heat)chamber | ||||||||||
| Advantages | This machine is featured with compact structure,, easy move,low noise and a small footprint.It's the best testing equipment choice for laboratory and office. | |||||||||
| Product Spec.and Technical parameter table | ||||||||||
| Model | MC-30A | MC-711 | ||||||||
| Volume | 30L | 60L | ||||||||
| Inside dimension(mm) | W30×H375×D400 | W400×H375×D400 | ||||||||
| Exterior dimension(mm) | W460×H400×D250 | W900×H1200×D610 | ||||||||
| Performance | temperature range | -40~+150°C | -60~+150°C | |||||||
| temperature fluctuation | ±0.5°C(no-load) | ±0.5°C(no-load) | ||||||||
| temperature deviation | ±2°C(no-load) | ±2°C(no-load) | ||||||||
| heating time | +20°C~+150°C≤30min | +20°C~+150°C≤30min | ||||||||
| cooling time | +20°C~-40°C≤60min(no-load) | +20°C~-70°C≤60min(no-load) | ||||||||
| Attemperation | Balance Thermal Control (BTC) | |||||||||
| Environment temperature | +5°C-+35°C | |||||||||
| Material | shell | Cold rolled sheet steel, spray plastics on surface | ||||||||
| Inner | steel plate SUS 304 | |||||||||
| insulate | Rigid Polyurethane Foam + Glass fibre | |||||||||
| heater | nickel chromium heater | |||||||||
| Regulating system | blower | Stainless Steel axial flow fan | ||||||||
| Compressor | fully enclosed and low noise compressor | |||||||||
| refrigerant | R404A | R404A/R23 | ||||||||
| cooling mode | Mechanical compression of single stage refrigeration(air-cooling) | Mechanical compression of binary cascade refrigeration(air-cooling) | ||||||||
| monitor | 5.7 Inch color LCD panel | |||||||||
| Controller | Mode of operation | procedure&set | ||||||||
| Method of Setting | Touch the English or Chinese into the form | |||||||||
| Display resolution | 0.01ºC;0.1min;o.o1%RH | |||||||||
| input | Pt100 RTD | |||||||||
| communication Interface | R232 interface | |||||||||
| Method of control | anti-windup PID | |||||||||
| Power Supply | AC380V(50±0.5)Hz Three-phase four-wire+protective earth wire | |||||||||
| Standard Configuration | 1 inspection window,2 sets of specimen holder ,1 fairlead. | |||||||||
| Safety device | ELCB,Fan overheating protection,Compressor overpressure,overheating,OCP,Phase order protection,overheat, temperature fuse,Dry protector,Water system protection,Water break . | |||||||||
Packaging & Delivery
Packaging: Wooden Box
Delivery:Shipped in 4~6 weeks after payment
