Ball Mill For Customization
USD $1000 - $2000000
/ Set
1 Set(Min.Order)
- 30 Set / Sets per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal Other Cash Escrow
- 30 days
You May Like
- Second-hand sweeper second-hand mobile phone curved glass sweeper tablet computer curved glass sweeper
- Automatic Ultrafine Powder Grinder with Ceramic Mortar
- Automatic Powder Grinder with Ceramic Mortar
- Pneumatically-lifted Laboratory Grinder (Special grinding equipment for scientific research in Colleges and Universities)
- Pneumatically-lifted Grinder with Double Pestle and Ceramic Mortar (manual discharging)
- Pneumatically-lifted Grinder with Ceramic Mortar (Large grinder for chemical material and new material)
Product Details
Brand Name: | Guikuang | Place of Origin: | China | Type: | Universal |
Condition: | New |
Product Description
Ball Mill Parameter | ||||||||||
MIll | NO | Specific | Capacity | Motor | Reducer | Transmission Way | Rotate Speed | Load of Grinding Media(t) | ||
Model | Power (KW) | Model | Speed Ratio i | |||||||
Cement | 1 | φ3×11m | 36-46(Circle flow) | YR1250-8/1430 | 1250 | MBY900 | 7.1 | edge | 18.8 | 95 |
2 | φ3×11m | 35-40 | YR1250-8/1430 | 1250 | MBY900 | 7.1 | edge | 18.8 | 95 | |
3 | φ3×7.5m | 35-40(Circle flow) | YR1000-8/1180 | 1000 | JD800B | 5.6 | edge | 18.6 | 65 | |
4 | φ2.6×13m | 36-42 | YR1000-8 | 1000 | JDX800 | 6.3 | edge | 19.5 | 78 | |
5 | φ2.4×13m | 20-23 | YR800-8/1180 | 800 | MBY710 | 6.3 | edge | 17.9 | 70 | |
6 | φ2.4×12m | 20-23 | YR800-8/1180 | 800 | MBY710 | 6.3 | edge | 20.8 | 60 | |
7 | φ2.4×11m | 18-21 | YR560-8 | 630 | ZD80 | 5 | edge | 20.5 | 52 | |
8 | φ2.4×10m | 18-21 | YR630-8/1180 | 630 | MBY560 | 5 | edge | 20.5 | 52 | |
9 | φ2.4×8.75m | 16-19 | JR1512-8 | 570 | ZD805-9-Ⅱ | 4.85 | edge | 20.09 | 40-43 | |
10 | φ2.4×8.5m | 19-22(Circle flow) | JR1510-8 | 475 | ZD805-9-Ⅰ | 4.85 | edge | 21.09 | 40 | |
11 | φ2.4×8.5m | 16-19 | JR1512-8 | 570 | ZD805-9-Ⅱ | 4.85 | edge | 21.09 | 40 | |
12 | φ2.4×8.5m | 19-22(Circle flow) | JR1510-8 | 475 | ZD805-9-Ⅰ | 4.85 | edge | 21.09 | 40 | |
13 | φ2.4×8m | 16-18 | JR1510-8 | 475 | ZD805-9-Ⅰ | 4.85 | edge | 21.09 | 40-45 | |
14 | φ2.2×11m | 14-16 | JRQ1512-8 | 570 | ZD80 | 5 | edge | 20.4 | 45 |
Working Principle
Ball Mill is a key equipment to grind the crushed materials, which is widely used in the manufacturing industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics.
