Help CenterAC Three Phase 50/60 hz 300KW 375Kva Weichai Diesel Generator
Related Products
-
360KW 450Kva Weichai Diesel Generator for Open Silent Container Trailer TypeUS$ 500 - 50,000MOQ: 1 Set -
Weichai 120KW 150 Kva Diesel GeneratorUS$ 2,360 - 5,000MOQ: 1 Set
-
Hot Sale ! Weichai Yangdong Engine 16KW 20Kva Diesel GeneratorUS$ 2,800 - 3,100MOQ: 1 Set
-
Cheap Price AC 50Hz 3 Phase Diesel Power 100kw Silent Diesel GeneratorUS$ 1,670 - 5,000MOQ: 1 Set
-
Silent 300kw Diesel GeneratorUS$ 1,670 - 5,000MOQ: 1 Set
Technical parameters of diesel generator sets: |
||
Technical data |
||
Genset Model |
WPG412.5B8 |
|
Prime Power |
300KW/375KVA |
|
Rated Voltage |
400/230V |
|
Frequency |
50/60Hz |
|
Power Factor |
0.8(lagging) |
|
The regulating rate of steady voltage |
≤±0.5% |
|
The regulating rate of instantaneous voltage |
≤-15%/ +20% |
|
The time of steady voltage |
≤1.5sec |
|
The waving rate of voltage |
≤1.0% |
|
The regulating rate of steady frequency |
≤3% |
|
The regulating rate of instantaneous frequency |
≤±10% |
|
The time of steady frequency |
3sec |
|
Dimension (L×W×H) (mm) |
2470*930*1440 |
|
Genset weight (kg) |
1650 |
|
Diesel Engine |
||
Brand |
Weichai |
|
Model |
WP13D385E200 |
|
Number of Cylinders |
6 |
|
Rotating Speed |
1500/18000RPM |
|
Cycle |
Four stroke |
|
Type |
waste gas turbine boost,direct spurting type |
|
Bore×Stroke(mm) |
127*165 |
|
Displacement(L) |
12.54 |
|
Lubricating Capacity(L) |
36 |
|
Speed Governor |
Electrical |
|
Cooling System |
Water-cooled |
|
Speed Stability (%) |
≤5% |
|
Fuel Consumption at 100% Load |
197g/kw.h |
|
Starting Method |
DC24V Electrical starting |
|
Alternator |
||
Brand |
Stamford type |
|
Model |
HCI444FS |
|
Number of Phase |
3 |
|
Connecting Type |
Three Phase and Four Lines |
|
Number of Bearing |
1 |
|
Grading Protection |
IP22 |
|
Altitude |
≤1000m |
|
Exciter Type |
Brushless (AVR automatic voltage regulating) |
|
Insulation Class |
H degree |
|
The components of the genset |
||
(1) Cummins Diesel Engine; (2)Shanghai Stamford Alternator; (3) Control Panel |
||
The control panel is Quadruplication protection control panel, with the display of frequency table/water temperature/schedule/battery voltmeter. The genset with low oil pressure, high water temperature, over speed emergency, stop and other pre-protection. |
||
Specifications
1.On Time Delivery
2.Matrial:Original spare parts
3.large stock for common parts
fessional engine parts sales engineer to guarantee the accuracy of the parts
5.Professional Perfomance Auto & Construction Machinery parts supplier
6.Diesel Engines for Wechai Shangchai (SDEC) Yuchai Deutz
Gensets model |
Rated capacity (Kva/kw) |
Standby capacity (kva/Kw)
|
rated current(a) |
rated fuel consumption ratio(l/h) |
Engine rated power (kw)
|
Engine cylinder numbers |
engine starting method |
overall dimensions(mm) |
Gross weight
(kg)
|
WPG13.5B1 |
12.5/10 |
13.5/11 |
18 |
3 |
18 |
4 |
electric |
1500x850x1250 |
499 |
WPG16.5B1 |
15/12 |
16.5/13.2 |
22 |
3.5 |
18 |
4 |
electric |
1500x850x1250 |
503 |
WPG22B1 |
20/16 |
22/17.6 |
29 |
4.5 |
23 |
4 |
electric |
1500x850x1300 |
590 |
WPG27.5B1 |
25/20 |
27.5/22 |
36 |
6 |
30 |
4 |
electric |
1500x850x1300 |
625 |
WPG33B1 |
30/24 |
33/26.4 |
43 |
7 |
30 |
4 |
electric |
1500x850x1300 |
631 |
WPG41B1 |
37.5/30 |
41/33 |
54 |
8.5 |
36 |
4 |
electric |
1500x850x1300 |
683 |
WPG55B9 |
50/40 |
55/44 |
72 |
10.8 |
60 |
4 |
electric |
2050x1080x1665 |
1161 |
WPG68.5-9 |
62.5/50 |
68.5/55 |
90 |
14 |
60 |
4 |
electric |
2050x1080x1665 |
1191 |
WPG88B9 |
80/64 |
88/70.4 |
115 |
17.3 |
90 |
4 |
electric |
2220x1050x1665 |
1337 |
WPG110B9 |
100/80 |
110/88 |
144 |
21.6 |
90 |
4 |
electric |
2220x1050x1665 |
1372 |
WPG123.5B9 |
112.5/90 |
123.5/99 |
162 |
24.1 |
120 |
6 |
electric |
2575x1050x1775 |
1658 |
WPG137.5B9 |
125/100 |
137.5/110 |
181 |
26.8 |
120 |
6 |
electric |
2575x1050x1775 |
1663 |
WPG165B9 |
150/120 |
165/132 |
217 |
32.2 |
138 |
6 |
electric |
2575x1050x1775 |
1718 |
WPG206 |
187.5/150 |
206/165 |
271 |
39.4 |
182 |
6 |
electric |
3010x1340x2060 |
2340 |
WPG247.5 |
225/180 |
247.5/198 |
324 |
47.2 |
216 |
6 |
electric |
3010x1340x2060 |
2460 |
WPG275 |
250/200 |
275/220 |
361 |
52.5 |
240 |
6 |
electric |
3010x1340x2060 |
2480 |
WPG344 |
312.5/250 |
344/275 |
451 |
65.6 |
290 |
6 |
electric |
3130x1400x2020 |
2680 |
WPG412.5 |
375/300 |
412.5/330 |
541 |
77.6 |
350 |
6 |
electric |
3240x1410x2100 |
3100 |
WPG440B8 |
375/320 |
440/352 |
577 |
82.8 |
368 |
6 |
electric |
3240x1410x2100 |
3125 |
More Details Information Please Contact Us
Diesel Engines for Wechai Shangchai (SDEC) Yuchai Deutz Ricardo Lovol Cumminss...and so on
Specifications
1.On Time Delivery
2.Matrial:Original spare parts
3.large stock for common parts
fessional engine parts sales engineer to guarantee the accuracy of the parts
5.Professional Perfomance Auto & Construction Machinery parts supplier
6.Diesel Engines for Wechai Shangchai (SDEC) Yuchai Deutz Cummins
B and F series product
1. Original European Technology, Independent R and D.
2. Gen-sets Power Matching Coefficient.
3. Matched with Professional High-temperature Radiator.
4. Professional Application and Integration Capabilities.
5. Option Automation, Auto-switch, Auto-parallel Connection and other Functions Freely.
6. Key Components of The Controller, Circuit Breakers, Generators for the Domestic and International Famous
7.Strong power,high reliability
Our most professional packaging
Transport of large trucks to the seaport
And international transport cooperation
1. 100% original parts
2. On Time Delivery
3.Factory Direct Price
fessional engine parts sales engineer to guarantee the accuracy of the parts
5. We will reply you for your inquiry in 24 hours.
6. after sending, we will track the products for you once every two days, until you get the products. When you got the
goods, give me a feedback.If you have any questions about the problem, contact with us, we will offer
the solve way for you.
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,
we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 5 to 30 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and
the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
