GH-E Vacuum Coating Thickness Tester
Application
GH-E Vacuum Coating Thickness Tester can be applied to various vacuum aluminum film, aluminized paper, and other conductive coating materials to test the resistance value, evenness, thickness and so on.
Standard
GB/T 15717
Specification
Item |
Technical Parameters |
Thickness test range |
50-1200(Å) |
Square resistance test range |
0.3~10Ω |
Test precision |
±0.5% Fs |
Test sample size |
300mm×100mm |
Test sample valid size |
300mm×100mm |
Instrument size |
300mm×300mm×150mm |
Power |
1000W |
Power supply |
AC 220V,50Hz |
Features
u Advanced circuit design assures the accuracy and stability of the test results.
u Adopt single-chip microcomputer to catch information, deal with data and control actions. With automatically report communication anomaly.
u Microcomputer controlling brings to fast processing speed, precise control, reliable safety and intelligent operation.
u Color LED touch screen, friendly man-machine interface allows users to check the data and test results quickly and visually.
u High precision contact testing method, reaching a high test accuracy of ±0.001Ω.
u Real time display of resistance value (maximum, minimum, average) and thickness (maximum, minimum, average).
u Configured with micro printer, which can quickly print out square resistance (maximum, minimum, average), thickness (maximum, minimum, average), and evenness.
u Based on actual demands, users can set number of test times to directly get the thickness result.
certificate
Our factory and lab
