Advanced Control System:
Independent temperature control partitions(control temperature for wax of partitions);Accurate wax flow and Injection Pressure.
Convenience : Maximum memory is 50 sets parameters .
Safety : Auto alarm system to fix faults in time.
No. | Description | Specification | |||
1 | Model | FG-ZLJ10 | FG-ZLJ25 | FG-ZLJ50 | FG-ZLJ100 |
2 | Construction | Double Station/Pillars | Single Station /C type | Single Station /C type | Single Station /C type |
3 | Clamp Force | 10 ton | 9-25 ton | 9-50 ton | 100 ton |
4 | Wax Reservoir Capacity | 113L | 113L | 113L | 113L |
5 | Single Shot Capacity | 1.2 L/station | 0～2.5 L | 0～6.5 L | 0～6.5 |
6 | Injection Pressure | 3.5 – 70 bar | 3.5 – 70 bar | 3.5 – 70 bar | 3.5 – 70 bar |
7 | Electrical Standard | 380V±10%, 50±2Hz, 3ph | 380V±10%, 50±2Hz, 3ph | 380V±10%, 50±2Hz, 3ph | 380V±10%, 50±2Hz, 3ph |
8 | Power | 19.5 KVA | 14.5 KVA | 14.5 KVA | 17 KVA |
9 | Air requirement | 5.3 bar | 5.3 bar | 5.3 bar | 5.3 bar |
10 | Telecommunication | Optional | Optional | Optional | Optional |
