Multi-purpose drying oven
Application:
Applicable to electrical, electronics, instrumentation, materials, medicine and other scientific research, production units, mainly used for drying, baking, heat treatment, disinfection, insulation and other temperature tests.
Features:
Testing chamber of drying oven is made of cold-rolled steel or stainless steel, and is manufactured by argon arc welding process. Double layers silicone rubber seals and mechanical locking devices effectively seal the test chamber. The shell of the drying oven is made of cold-rolled steel sheet, and the double sides electrostatic epoxy polyester powder is sprayed at 180℃ for curing. The gap between the test chamber shell and the test chamber is filled with centrifugal glass wool felt to achieve the lowest heat loss.
Customers can adjust the height of the shelf as needed to make more efficient use of space.
Forced air convection duct structure; the air duct is located on the left side of the oven, and the control cabinet is located at the left of the oven.
Safety：
Use SUS304 stainless steel electric heating pipe sealed heating, and set pressure relief safety door; have power supply leakage and heater short circuit protection, to ensure safe operation.
Technical parameter:
Model |
HD-2006BDG |
HD-202BDG |
HD-302BDG |
|
Volume |
640 L |
2460 L |
2460 L |
|
Internal dimensions (D*W*H) |
800 *800 *1000 mm |
1100*1500*1600 mm |
1100*1500*1600 mm |
|
External dimensions (D*W*H) |
1070*1300*1280 mm |
1440*2070*1900 mm |
1440*2070*1900 mm |
|
Performance | ||||
Maximum temperature |
200℃ |
300℃ |
||
Minimum temperature |
Room temperature +20℃ |
|||
Heating time |
Room temperature....200℃ ≤ 60 min |
Room temperature....300℃ ≤ 90 min. |
||
Temperature fluctuation |
≤ ± 0.5℃ |
|||
Temperature uniformity |
≤ ± 2.5% |
|||
Controller |
Digital temperature controller, with self tuning PID function; |
|||
Heater |
Nickel-chromium heating wire |
|||
Power supply |
AC 380V/ 50Hz, Three-phase four-wire + earth wire |
|||
Power |
5.5 kW |
17.5 kW |
17.5 kW |
|
Noise |
68 dB(А) |
68 dB(А) |
68 dB(А) |
|
