Help CenterHZ-130Y Geological Survey Drilling Machine 100 Meters Deep Water Well Rigs
Related Products
-
HZ-130YY Water Well Drilling Machine Hydraulic Core Exploration EquipmentUS$ 4000 - 6000MOQ: 1 Set -
XYX-130 Wheel Type Hydraulic Drill Water Well MachineUS$ 4000 - 6000MOQ: 1 Set
-
XYD-130 Crawler Type Hydraulic Rock Layer Exploration Drilling MachineUS$ 6000 - 7500MOQ: 1 Set
-
HZ-200Y Type Civil Water Well Conditioning Drilling MachineUS$ 4000 - 8000MOQ: 1 Set
-
HZ-200YY Hydraulic Core Sampling Drilling MachineUS$ 4000 - 6000MOQ: 1 Set
Keywords: small drilling machine,hydraulic press machine, water well drilling rig
1. The applications of HZ-130Y water well drilling rig
Field irrigation well, civil use water well, ground temperature central air conditioning and so on; geological survey and exploration, basic exploration for roads and high-rise buildings, inspection holes for various concrete structures, river embankments, subgrade grouting holes.
1. The features of HZ-130Y water well drilling rig
l The hoisting machine is equipped with a holding frame to form a double-sided supporting star wheel structure,can withstand strong impact.
l Four groups of bearings are positioned in the vertical shaft box to ensure that the gyration is rigid enough to cope with the complex geological conditions such as the gravel layer and the pebble layer.
l This machine adopts the conical clutch of national patent technology, which has the prominent characteristics of large transmission torque, convenient operation and no maintenance.
l Using 53 ×59 six party active drill rod, strong rigidity, large torque transmission.
3. Specifications of HZ-130Y water well drilling rig
HZ-130Y drilling rig | |
Drilling depth |
130m |
Maximum open hole diameter |
220mm |
End hole diameter |
75mm |
Drilling pipe diameter |
50mm |
Drilling angle |
90°-75° |
Weight |
750kg |
Power |
Diesel engine 13.2kw |
Spindle | |
Spindle rotating speed |
142 285 570r/min |
Spindle stroke |
450mm |
Windlass | |
The maximum weight of a single rope |
1600kg |
Lifting speed of a single rope |
0.41 0.82 1.64m/s |
Drum diameter |
140mm |
Wire rope diameter |
13mm |
Drum capacity |
27m |
Mud pump | |
Model |
Horizontal single cylinder double action |
Displacement ( diesel and electric, respectively) |
95L/ MIN,77L/MIN |
Maximum pressure |
1.2mpa |
Working pressure |
0.7mpa |
Water inlet diameter |
30mm |
Water outlet diameter |
20mm |
Triangle belt diameter |
B1575mm |
