| Features & Benefits |
|
1.Flow rate up to 3.3 GPM [12.5 LPM] 3.Automatically turn on and off 5.Quiet operation 7.On demand & by pass use |
2.Can run dry without damage 4.Self priming & built-in check valve 6.Chemically resistant materials 8.Designed for spraying and fluid transfer |
| Product Name | SEAFLO dc 3m 200 psi Commercial Duty Water Bronze Pressure Washer Pump Camping |
| Pump Type | 4 Chambers Positive Displacement Diaphragm Pump |
| Max Flow Rate | 3.3 GPM [12.5 LPM] |
| Max Pressure | 35 PSI [2.4 Bar] |
| Voltage | 12 VDC, and 24V, 115V, 230V are available |
| Max Amp | 15.0 A |
| Fuse | 22.5 A |
| Switch Type | On Demand [Cut-off Switch] & By Pass, and none switch is available |
| Diaphragm Material | Santoprene |
| Valve Material | Viton, and EPDM is available |
| Duty Cycle | Intermittent |
| Self Priming | 6' [1.8 m] suction |
| Max Fluid Temp | 140 °F [60 °C] |
| Inlet & Outlet Port | 3/4" [19 mm] Quick Connect, and contact us for more ports |
| Lead | 11" [28 cm] 16 AWG lead |
The 41 Series pump provides high volume water flow with reduced pump cycling, thanks to the quad chamber diaphragm and internal bypass. The Four-chamber high volume design, driven by a heavy-duty motor, produces flow rates of 3.3 to 4.5GPM , With on-demand switching. The 41-Series pumps are self-priming, and can run dry without damage, performance reliable and low current. Seaflo also offers a variety of Easy Connect fittings and filters
| Product Show |
| Dimensions |
| Performance |
| Motor Heat Rise |
| Product Details |
Standard Pump Configurations
| Model | Voltage |
Open Flow GPM [LPM] |
Cut off Pressure PSI [BAR] |
Max Draw | Diaphragm | Valve |
| SFDP1-033-035-41 | 12 V | 3.3 [12.5] | 35 [2.4] | 8.0 A | Santoprene | Viton |
| SFDP2-033-035-41 | 24 V | 3.3 [12.5] | 35 [2.4] | 4.0 A | Santoprene | Viton |
| SFDP1-040-060-41 | 12 V | 4.0 [15.0] | 60 [4.1] | 14.0 A | Santoprene | Viton |
| SFDP2-040-060-41 | 24 V | 4.0 [15.0] | 60 [4.1] | 7.0 A |
Santoprene | Viton |
| SFDP1-045-060-41 | 12 V | 4.5 [17.0] | 60 [4.1] | 16.0 A | Santoprene | Viton |
| SFDP2-045-060-41 | 24 V | 4.5 [17.0] | 60 [4.1] | 8.0 A | Santoprene | Viton |
OEM/ODM service: Cut off pressure can be adjusted from 17 PSI [1.17 Bar] to 60 PSI [4.1 Bar]; Open flow can be adjusted from 0.8 GPM [3.0 LPM] to 4.8 GPM [17.0 LPM]. Material can be adjusted according to your requirement.
Package Infomation
|
|
Unit Pump Weight | 3.91 lbs [1.77 kg] |
| Selling Unit Size (L x W x H) | 11.81" x 5.12" x 4.33" [30.0 x 13.0 x 11.0 cm] |
|
| Selling Unit Weight | 4.54 lbs [2.10 kg] | |
| Master Carton Qty | 10 pcs / carton | |
| Master Carton Size (L x W x H) | 18.11" x 12.99" x 10.04" [46.0 x 33.0 x 25.5 cm] |
|
| Master Carton Weight | 46.94 lbs [21.29 kg] |
More flow and pressure are available, please contact us to get catalog and price list.
Q: What is your MOQ?
A: 100 pieces in general, but no MOQ requirement for sample testing.
Q: Do you accept OEM/ODM service?
A: Yes. We are also the OEM/ODM supplier for many famous companies, such as Volvo, Bunnings etc.
Q: How can I pay for my order?
A: Please send order details to us. We will issue an order on Alibaba Trade Assurance, and send you the payment link.
Q: What is your terms of payment?
A: Payment≤3000USD, 100% in advance. Payment≥3000USD, 30% T/T in advance, balance against the copy of B/L. If you have another question, pls feel free to contact us.
Q: What is the delivery time?
A: It depends on the order quantity. It usually takes 15-25 days upon receipt of your 30% deposit by T/T. Sample can be delivered within 7 days.
Q: Can I buy different products in one container?
A: Yes, you can mix different models of pumps in one container.
Q: What is your warranty?
A: 1 year, and within 24 hours reply will be provided to solve customers' problems.
Q: What is your port of loading?
A: Xiamen port.
Q: Do you have oversea agents?
A: We dont have oversea agents for Agriculture and Industrial. But for SEAFLO pumps applied in Marine & RV, we have agents in USA, UK, Denmark, Spain, Australia, Turkey, Yemen, Lebanon etc.
Q: Can I get more info?
A: Please visit or www.seafloin.en.china.cn for more information.
