Sine Image Grid Test Chart Grid Lines Chart Distortion Chart for TV Cameras

Sine Image Grid Test Chart Grid Lines Chart Distortion Chart for TV Cameras thumbnail-1
Sine Image Grid Test Chart Grid Lines Chart Distortion Chart for TV Cameras photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
Sine Image
Place of Origin:
China
Model Number:
NJ-10-100A
Contact Supplier Request Quote Chat Now
Shenzhen Threenh Technology Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen, China
Delivery Detail:
7 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name Sine Image
Place of Origin China
Model Number NJ-10-100A
Model NJ-10-100A
Type Reflective/Transparent
Format Custom Designs
Ratio 4:3

PRODUCT DETAILS

NJ-10-100A is designed for operational adjustment and control of TV cameras. It consists of circles permitting rough visual appraisal of scan linearity, grid lines serving the purpose of adjusting registration and wedges serving the purpose of resolution appraisal.

A grid structure consisting of 23 horizontal and 35 vertical lines is arranged on a white background. 3 grid lines each divide the outer 3 grid rows in the middle. The width of the grid lines is 0.15% of the picture width. The large circular line has a diameter of 83 1/3% of the picture height, the 5 small circular lines have a diameter of 25% of the picture height.

4 resolution wedges are arranged in the large circle at angles of 0°, 45°, 90°, and 135° corresponding to signal frequencies of 2-10 MHz. (The marking ends at 8 MHz and 600 lines).

UTILIZATION

  • The test chart is designed for operational adjustment and control of TV cameras.

  • The circles permit rough visual appraisal of scan linearity.

  • The grid lines serve the purpose of adjusting registration.

  • The wedges serve the purpose of resolution appraisal.



Product Tags: Grid Test Chart TV Cameras , Resolution Test Chart Target
