Home > Instruments & Meters > Analysis Instrument > Other Analysis Instruments > 3NH D/8° Spectro Colorimeter 4mm Aperture Accurate Color Analyzer for Cloth Metal Liquid Masterbatch
3NH D/8° Spectro Colorimeter 4mm Aperture Accurate Color Analyzer for Cloth Metal Liquid Masterbatch
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
3nh
Place of Origin:
China
Model Number:
NS820
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen, China
Delivery Detail:
2 days
Related Products
-
3NH 45°/0° Spectrophotometer 8mm Aperture Traffic Sign Measurement Version Portable ColorimeterNegotiableMOQ: 1 Piece -
3NH UV Grating Spectrophotometer 8/4mm Aperture High Accuracy Instrument for Plastic Paint Printing TextileNegotiableMOQ: 1 Piece
-
3NH Color Spectrophotometer With Customized Aperture High Accuracy Instrument for Plastic Paint Printing TextileNegotiableMOQ: 1 Piece
-
3NH Handheld Spectrophotometer 8mm Aperture High Accuracy Colorimeter for Plastic Paint Printing TextileNegotiableMOQ: 1 Piece
-
3NH D/8 Grating Spectrophotometer 8/4mm Customized Aperture Full Spectrum LED Light Source Colorimeter for Plastic Paint Printing TextileNegotiableMOQ: 1 Piece
Brand Name
3nh
Place of Origin
China
Model Number
NS820
Company Brief Introduction:
Shenzhen Threenh Technology Co., Ltd.(Hereinafter referred to as 3nh) is a high-tech enterprise. We've been researching, developing, producing and marketing photoelectric detection products since 1998.
3nh team has strong capability to design, develop and produce in photoelectric detection technology field and color management field.
3nh products obtain a large number of innovation , core technologies and intellectual property rights. They are widely used in plastic, electronic, paint, ink, textile, garment, printing and dyeing, food, , cosmetic, optical image test industries and the field of scientific research, school and laboratory.
Our products are exported around the world and customization service is also available. Please feel free to contact us for more cooperation discussing.
| Model | NS800 | NS810 | NS820 | NS808 Traffic Sign version |
| Optical Geometry | (45°ring-shaped illum45in°/a0t°ion, vertical viewing) | D/8° | D/8° | 45°/0° |
| Integrating Sphere Size | Φ58mm | |||
| Light Source Device | Combined LED light sources | |||
| Sensor | Silicon Photodiode | |||
| Light wave range | 400~700nm | |||
| Wavelength Pitch | 10nm | |||
| Reflectance Range | 0~100% | 0~200% | ||
| Measuring Aperture | Φ8mm | Φ8mm | Φ4mm | Φ8mm |
| Color Space | CIE LAB,XYZ,Yxy,LCh,CIE LUV,HunterLAB | CIE LAB,XYZ,Yxy,LCh,CIE LUV | ||
| Color Difference Formula | ΔE*camb,cΔ(E1*:914),,ΔΔEE**0c0m,cΔ(E(2:h1)),,ΔE*cmc(l:C) | ΔE*ab,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00,ΔE*cmc(l:C) | ||
| Other Colorimetric Data | WI(ASTM E313,CIE/ISO,AATCC,Hunter),YI(ASTM D1925,ASTM 313), TI(ASTM E313,CIE/ISO), Metamerism Index(MI), Color Strength, Color Stain, Color Fastness,Opacity | Increase coverage | ||
| Observer | 2°/10° | |||
| Illuminant | D65,A,C,D50,D55,D75,F2,F6,F7,F8,F10,F 11,F12 | increase F1,F3,F4,F5,F9 | ||
| Displayed Data | Spectral Value/Graph, Colorimetric Value, Color Difference Value/Graph, PASS/FAIL Result, Color Offset, Color Simulation | No color simulation | ||
| Measurement Time | 1.5s | |||
| Repeatability | Spectral Reflectance: standard deviation within 0.1%(400~700nm: within 0.2%) | |||
| Ingtreere-imnsetnrtument | ΔE*ab less than 0.2(average value for measuring BCRI series II 12pcs palettes) | |||
| Size | L*W*H= 90*77*230(mm) | |||
| Weight | about 600g | |||
| Battery Performance | Li-ion Battery : 5000 times within 8 hours | |||
| Lamp Life | 5 years, more than 1.6 million measurements | |||
| Display | 3.5-inch TFT color LCD, Capacitive Touch Screen | |||
| Interface | USB | |||
| Data Storage | Standard: 1000, Sample: 10000 | |||
| Operating Environment | 0~40ºC(32~104°F) | |||
| Storage Environment | -20~50ºC(-4~122°F) | |||
| Standard Accessories | Power Adapter, Li-ion Battery, Operating Instruction, CD-ROM (containing management software), Data Line, White and Black Calibration Cavity, Protective Cover and Wrist Strap | |||
| Optional Accessories | Universal Test Component, Micro Printer, Powder Test Box,Multifunctional test component | |||
