QTZ-4 Diesel engine portable soil sampling drilling rig
1.Brief introduction of QTZ-4 Diesel engine portable soil sampling drilling rig
QTZ-4 diesel engine portable soil sampling drilling rig is a special soil sampling drilling rig that developed according to the actual needs of large depth soil sampling with small machine. The new QTZ-4 soil drilling rig applies the vibration shock theory with the advantages of large energy, small size, light weight, simple structure, simple operation, and two people can carry out sampling operations.
2.Parameters of QTZ-4 Diesel engine portable soil sampling drilling rig
QTZ-4 Diesel engine portable soil sampling drilling rig | ||
Diesel engine |
Model |
R175B |
Type |
Horizontal, single-cylinder, four-stroke,water-cooled |
|
Power |
4.85kW |
|
Max.impact energy |
110.46N.m |
|
Excitation force amplitude |
1041.8-4167.2N |
|
Exciter amplitude |
14.1- 40mm |
|
Flexible shaft length |
5m |
|
Coring depth |
20m-25m |
|
Weight of exciter |
35kg |
|
