1500 Water Meters Transmission Distance Lora Wireless S9 Valve Controlled

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port ShenZhen
Payment TermsT/T L/C D/P D/A Money Gram Credit Card PayPal Other Cash Escrow

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

Yomtey

Product Description

Overview

The wireless remote valve control water meter belong to high-tech products in the smart water meter, using of advanced wireless transmission technology, it transforms metered information of conventional mechanical water meter into electrical signal have it stored by micro-electronics control circuit. It is able to automatically read the metering data via wireless remote network and is also able to transfer the data to the back-office system (data center) after reading the meters.

Technical parameters

1, Flow range

Model No.	Nominal diameter DN(mm)	Turndown ratio	Overload flow Q4	Permanent flow Q3	Transitional flow Q2	Min flow Q1
			Overload flow Q4	Permanent flow Q3	Transitional flow Q2	Min flow Q1
			m³/h
DN15	15	R80	3.125	2.5	0.05	0.031
DN20	20	R80	5.0	4.0	0.08	0.05

2, Wireless technology parameters

Power Supply	(2.1～3.6)V
Working Frequency	(866～868)MHz
Transmit Power	50mW
Receiver Sensitivity	-132dBm
Sleep Current	2.5uA
Average Current	18uA
Transmission Distance	1500 meters transmission distance (5Kbps visual distance)
Operating Temperature	(-20～70)℃
Routing Progression	Level 8

Description

1. Before using this watch, the user must go to the management office of the management department to open an account and establish a file. After verifying the information is correct, it can be used; otherwise, it may cause unnecessary losses;

2. The frequency of wireless meter reading meter data is not more than 1 time/day, otherwise it will affect the service life of the battery;

3. If the water meter is submerged under water, it will greatly impair the ability of wireless transmission;

4. Record and check the reading of the mechanical water meter on a regular basis;

5, when you need to change the table, you need to log in the system to change the table operation.
