DN125 Water Meter Movement Large-caliber Ultrasonic Water Meter With Intelligent Measuring Instruments

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Port ShenZhen
Payment TermsT/T L/C D/P D/A Credit Card PayPal Other Cash Escrow

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

Yomtey

Product Description

Overview

Ultrasonic water meter is intelligent measuring instruments by the temperature sensor, flow sensors and calculators. Calculator used the sensor and through the water of time difference to collect temperature differences and sound waves to complete accurate measurement of water flow. And can provide important application and data for many applications in the pipeline.Mainly used for water metering and monitoring water flow, such as domestic water, central air conditioning systems, equipment, etc.

Technical Parameter

Nominal diameter	15		20	25	32	40
Max flow Q4(m3/h)	3.125		5	7.87	12.5	20
Nominal flow Q3(m3/h)	2.5		4	6.3	10	16
Transitional flow Q2(m3/h)	0.02		0.032	0.05	0.08	0.128
Min flow Q1(m3/h)	0.013		0.02	0.032	0.05	0.08
Start-up flow(m3)	0.005		0.005	0.008	0.01	0.015
Max flow indicator(m³/h)	999999.99m³
Measuring range	Q3/Q1, R200
Accuracy class	Class B
Pressure loss	≤0.063 MPa
Working pressure	MAX1.6 MPa
Temp class	T50
Temp range		(5~55)℃
Installation environment		Indoor,Class B
Electromagnetic environment		E1(Residential, Commercial, Industrial)
Power supply		Built-in lithium battery DC 3.6V
Battery life		≥ 8years
Installation position		Horizontal or Vertical
Display		LCD, 8 digits + additional characters
Installation pitch		U10/D5
Interface		RS 485/M-bus
Protection class		IP68
Data storage		storage of all monthly value of last 18 months
Flow measurement		Normal state:6 times/4 sec.(1 time/15 sec .under no water condition);Verification state:12 times/sec.
