Home > Electrical & Electronics > Optical Fiber, Cable & Wire > Electric Wire & Cable > 4core 26AWG Cable Rov

4core 26AWG Cable Rov

Name: 4core 26AWG Cable Rov
Brand: hongsheng
SKU: 162257983
Availability: InStock

US$ 0.9 - 0.9 MOQ: 500 Meters

Key Specifications

Get Latest Price

Brand Name:

hongsheng

Place of Origin:

Shanghai, China

Type:

Low Voltage

Contact Supplier Request Quote Chat Now

Shanghai Kabel Intelligence Technolgy Co Ltd

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name hongsheng

Place of Origin Shanghai, China

Type Low Voltage

Application Marine

Insulation Material PE

Conductor Material Copper

Product Introduction

4core 26AWG cable rov

Floating Cable relies on foam core extrusion capabilities to achieve precise cable buoyancy requirements. It is flexible, movable,UV-stable, good bendability, and abrasion-resistant and may be fitted with choice of jackets to achieve resistance to various chemicals including acids, salt water, oil, and gasoline. Cable is suited for powering and controlling robotic cleaning systems in swimming pools and aquarium facilities as well as marine applications and submersible environmental pumping systems

4core 26AWG cable rov

Specification	Insulation Diameter(mm)	Sheath Diameter(mm)
2 x 12 AWG	4	18
2 x 16 AWG	2.9	12.4
2 x 18 AWG	2.4	10.2
2x16AWG + 1x18AWG	2.9/2.4	13.5
2x16AWG + 2x22AWG	2.9/2.0	13.2
4x16AWG + 2x20AWG	2.9/2.0	17.8
Coxial + 3x2x16AWG	/	/

Physical
Item	Value
Tether Diameter	7.6 mm	0.30 in
Weight	0.043 kg/m	0.0287 lbs/ft
Buoyancy in Freshwater	Neutral
Buoyancy in Saltwater	Slightly Positive
Wire Gauge	26 AWG
Working Strength	35 kgf	80 lbf
Breaking Strength	155 kgf	350 lbf
Minimum Working Bend Diameter	200 mm	8 in

Electrical
Item	Value
DC Resistance @ 20°C	0.0386 Ω / ft	0.127 Ω / m
Characteristic Impedance @ 1 MHz	120 Ω
Capacitance @ 1 kHz	16.5 pF / kft	54.1 pF / km
Insulation Resistance @ 500 VDC	> 500 MΩ / kft	> 1640 MΩ / km
Voltage Rating (Twisted Pair)	300 VDC
Voltage Rating (Between Pairs)	600 VDC

Welcome to inquiry at any time! We will offer you an accurate price within 12 hours!

Company Profile

Shanghai Hongsheng Wire & Cable Co., Ltd. is located in No. 4769, Money Road, Fengxian District, Shanghai. It was established in 1998. It is a high-tech enterprise in Shanghai specializing in R&D, design, production and sales of special wires and cables. The company has a number of inventions and practical patents. Has passed ISO9001 quality management system, China Quality Certification Center CCC, EU CE, Germany TUV and other certifications, the company's main products include: flexible mineral fireproof cable automation control cable planting power cable photovoltaic cable cloth wire and wind energy cable A series of specifications. In addition, buyers can also customize their own wire and cable according to their specific needs.
