4x28AWG Zero Buoyancy Underwater Rov Floating Camera Cable

4x28AWG Zero Buoyancy Underwater Rov Floating Camera Cable photo-1
4x28AWG Zero Buoyancy Underwater Rov Floating Camera Cable photo-2
4x28AWG Zero Buoyancy Underwater Rov Floating Camera Cable photo-3
US$ 0.9 - 0.9 MOQ: 500 Meters
Key Specifications
Get Latest Price
Brand Name:
hongsheng
Place of Origin:
Shanghai, China
Type:
Low Voltage
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Brand Name hongsheng
Place of Origin Shanghai, China
Type Low Voltage
Application Marine
Insulation Material PE
Conductor Material Copper
Product Introduction

4x28AWG Zero buoyancy underwater Rov floating camera cable



Floating Cable relies on foam core extrusion capabilities to achieve precise cable buoyancy requirements. It is flexible, movable,UV-stable, good bendability, and abrasion-resistant and may be fitted with choice of jackets to achieve resistance to various chemicals including acids, salt water, oil, and gasoline. Cable is suited for powering and controlling robotic cleaning systems in swimming pools and aquarium facilities as well as marine applications and submersible environmental pumping systems




4x28AWG Zero buoyancy underwater Rov floating camera cable
Specification
Insulation Diameter(mm)
Sheath Diameter(mm)
2 x 12 AWG
4
18
2 x 16 AWG
2.9
12.4
2 x 18 AWG
2.4
10.2
2x16AWG + 1x18AWG
2.9/2.4
13.5
2x16AWG + 2x22AWG
2.9/2.0
13.2
4x16AWG + 2x20AWG
2.9/2.0
17.8
Coxial + 3x2x16AWG
/
/
Physical
Item
Value

Tether Diameter
7.6 mm
0.30 in
Weight
0.043 kg/m
0.0287 lbs/ft
Buoyancy in Freshwater
Neutral

Buoyancy in Saltwater
Slightly Positive

Wire Gauge
26 AWG

Working Strength
35 kgf
80 lbf
Breaking Strength
155 kgf
350 lbf
Minimum Working Bend Diameter
200 mm
8 in
Electrical
Item
Value

DC Resistance @ 20°C
0.0386 Ω / ft
0.127 Ω / m
Characteristic Impedance @ 1 MHz
120 Ω

Capacitance @ 1 kHz
16.5 pF / kft
54.1 pF / km
Insulation Resistance @ 500 VDC
> 500 MΩ / kft
> 1640 MΩ / km
Voltage Rating (Twisted Pair)
300 VDC

Voltage Rating (Between Pairs)
600 VDC



Welcome to inquiry at any time! We will offer you an accurate price within 12 hours!


Case & Usings

4x28AWG Zero buoyancy underwater Rov floating camera cable


Welcome to inquiry at any time! We will offer you an accurate price within 12 hours!


Packing & Shipping

4x28AWG Zero buoyancy underwater Rov floating camera cable

Welcome to inquiry at any time! We will offer you an accurate price within 12 hours!


Company Profile

Shanghai Hongsheng Wire & Cable Co., Ltd. is located in No. 4769, Money Road, Fengxian District, Shanghai. It was established in 1998. It is a high-tech enterprise in Shanghai specializing in R&D, design, production and sales of special wires and cables. The company has a number of inventions and practical patents. Has passed ISO9001 quality management system, China Quality Certification Center CCC, EU CE, Germany TUV and other certifications, the company's main products include: flexible mineral fireproof cable automation control cable planting power cable photovoltaic cable cloth wire and wind energy cable A series of specifications. In addition, buyers can also customize their own wire and cable according to their specific needs.
