Help CenterTobee Pump Parts Bearing Assembly DAM005M Used for 6/4D-AH Slurry Pumps
Related Products
-
Slurry Pump Parts Packing D111-Q05A for 6/4 D AH Slurry PumpsUS$ 100 - 400MOQ: 1 Piece -
Tobee® Rubber Slurry Pump Parts ManufacturerUS$ 10 - 100MOQ: 1 Piece
-
Metal Slurry Pump Parts 100% Interchangeable With AH, AHR, HH, M, L Horizontal Slurry PumpsUS$ 10 - 100MOQ: 1 Piece
-
High Chrome Alloy Slurry Pump PartsUS$ 10 - 100MOQ: 1 Piece
-
Equivalent Slurry Pump Spare and Wearing PartsUS$ 10 - 100MOQ: 1 Piece
Tobee® Slurry Pump Bearing assembly also called rotor assembly, It is a large diameter shaft with short overhang minimizes deflection and contributes to long bearing life. Only four through bolts are required to hold the cartridge type housing in the frame. It is most important part for drive power unit. The bearing assembly is to connect the pump and motor as a complete pump working system. Its stability will directly affect pump operation and worklife.
Tobee® Slurry Pump Bearing Assembly Drawing:
Interchangeable Slurry Pump Bearing Assembly Code:
|
Bearing Assembly |
Tobee TH Slurry Pump | AH Slurry Pump | Remark |
| B005M | TH1.5/1B, TH2/1.5B | 1.5/1B-AH, 2/1.5B-AH | ZWZ, SKF, TIMKEN Brand |
| C005M | TH3/2C, TH4/3C | 3/2C-AH, 4/3C-AH | ZWZ, SKF, TIMKEN Brand |
| D005M | TH4/3D, TH6/4D | 4/3D-AH, 6/4D-AH | ZWZ, SKF, TIMKEN Brand |
| E005M | TH6/4E, TH8/6E | 6/4E-AH, 8/6E-AH | ZWZ, SKF, TIMKEN Brand |
| R005M | TH8/6R | 8/6R-AH | ZWZ, SKF, TIMKEN Brand |
| FAM005M | TH8/6F, TH10/8F, TH12/10F | 8/6F-AH, 10/8F-AH, 12/10F-AH | ZWZ, SKF, TIMKEN Brand |
| SH005M | TH10/8ST, TH12/10ST, TH14/12ST | 10/8ST-AH, 12/10ST-AH, 14/12ST-AH | ZWZ, SKF, TIMKEN Brand |
| TH005M | TH16/14TU, TH18/16TU, TH20/18TU | 16/14TU-AH, 18/16TU-AH, 20/18TU | ZWZ, SKF, TIMKEN Brand |
| Bearing Assembly | Tobee THH Slurry Pump | HH Slurry Pump | Materials |
| CAM005M | THH1.5/1C | 1.5/1C-HH | ZWZ, SKF, TIMKEN Brand |
| DAM005M | THH3/2D | 3/2D-HH | ZWZ, SKF, TIMKEN Brand |
| EAM005M | THH4/3E | 4/3E-HH | ZWZ, SKF, TIMKEN Brand |
| FAM005M | THH6/4F | 6/4F-HH | ZWZ, SKF, TIMKEN Brand |
| Bearing Assembly | Tobee TM Slurry Pump | M Slurry Pump | Materials |
| EAM005M | TM10/8E | 10/8E-M | ZWZ, SKF, TIMKEN Brand |
| R005M | TM10/8R | 10/8R-M | ZWZ, SKF, TIMKEN Brand |
| Bearing Assembly | Tobee TL Slurry Pump | L Slurry Pump | Materials |
| ASC005M | TL20A | 20A-L | ZWZ, SKF, TIMKEN Brand |
| BSC005M | TL50B | 50B-L | ZWZ, SKF, TIMKEN Brand |
| CAM005M | TL75C | 75C-L | ZWZ, SKF, TIMKEN Brand |
| DSC005M | TL100D | 100D-L | ZWZ, SKF, TIMKEN Brand |
| ESC005M | T150E | 150E-L | ZWZ, SKF, TIMKEN Brand |
| S005M | 300S-L | 300S-L | ZWZ, SKF, TIMKEN Brand |
| Bearing Assembly | Tobee TG(H) Gravel Pump | G(H) Gravel Pump | Materials |
| DAM005M | TG6/4D | 6/4D-G | ZWZ, SKF, TIMKEN Brand |
| EAM005M | TG8/6E | 8/6E-G | ZWZ, SKF, TIMKEN Brand |
| F005M | TG10/8F | 10/8F-G | ZWZ, SKF, TIMKEN Brand |
| S005-3M | TG10/8S, TGH10/8S | 10/8S-G, 10/8S-GH | ZWZ, SKF, TIMKEN Brand |
| G003M | TG12/10G, TG14/12G, TGH12/10G | 12/10G-G, 14/12G-G, 12/10G-GH | ZWZ, SKF, TIMKEN Brand |
| TH005M | TGH16/14TU | 16/14TU-GH | ZWZ, SKF, TIMKEN Brand |
Tobee® Slurry Pump Bearing Assembly Module Design:
|
|
|
• Grease Lubricated Bearing Assembly
The grease-lubricated bearing assembly houses a large-diameter shaft in its unique bearing cartridge designed specially for heavy-duty tasks. Due to its compact design, the bearing takes up little space while providing minimum vibration and deviation. Grease lubrication minimizes the possibility of oil leakage and little extra maintenance effort is needed. The rotor is easily adjustable. Users can install several rotors operating in series.
• Horizontal Axially-Split Bearing Assembly
Lubricated by oil, the axially-split bearing assembly features a large-diameter shaft and a short cantilever. It delivers high rigidity, and is unlikely to deform or vibrate even when highly abrasive solids are encountered. The bearing is directly mounted inside the bearing support which can be split into 2 halves along its center line. This mounting method allows for ease of disassembly, inspection and adjustment of bearing. Water cooling system effectively cools down the hot bearing, greatly improving its use life.
• Cartridge Type Oil-Lubricated Bearing Assembly
Spacious cartridge design allows for the installation of a large-diameter rotating shaft. Built specially to handle heavy-duty tasks, the metric size bearing is lubricated by thin oil. Users can install several bearings operating in series. Compact design and high reliability are 2 major benefits of this bearing for its end users.
Tobee® Slurry Pump Inspection Process:
| Stages of manufacture |
Quality control activities |
Standard |
| Pump design | Appearance, size | GB/10888-89 |
| Raw material arrival | Sampling, material chemical analysis | GB121.1-29-2008 |
| Casting and composition | Material chemical analysis of pump parts | GB121.1-29-2008 |
| Casting quality inspection | GB302-2012 | |
| Key component machining | Dimension precision inspection | JB/T6879-93 |
| Impeller balancing | GB061-2002 | |
| General assembly | Procedure operation | GB2103-96 |
| Hydraulic static test | GB064-2008 | |
| Painting | Anticorrosion primer paint | JB/T4297-92 |
| Epoxy coating | JB/T4297-92 | |
| Performance test of pump unit | Capacity and head | GB157-1998 |
| Vibration and noise | JB/T8097-05 | |
| Bearing temperature | JB/T5295091 | |
| Final inspection | Packaging of pump unit | GB0157-2008 |
| Technical documents | GB0157-2008 | |
| Spare parts and accessories | GB0157-2008 |
Tobee® Slurry Pumps After-sales Service:
As the slurry pump wet ends parts such as the impeller, volute liner, FPL insert, Throat bush and bearing assembly are consumption parts and we could provide you always the qualified slurry pump parts within very short time.
Packing Transport Services
Considering the order pump size and we could provide case or pallet as per your need to make sure it safe enough during the long distance road and ocean shipping. having own export company and so we could help you find the best ocean shipping solution and service for you from the goods out of factory to your destination.
Installation Services
Tobee Pump have more than 30 years experienced pump installation workers and are very aware of any onside application. We could provide abroad pump installation service and expect pump manufacturing and sales,abroad pump installation is getting more and more popular by our regular clients abroad.
Technical Support Services
Technical data sheet, Performance curve, General arrangement drawing, Operating manual will be sent within 24th for your checking, So Pls feel free to contact us If you have any need.
Tobee® Slurry Pump On-site Applications:
| • Wet crushers |
• SAG mill discharge |
• Ball mill discharge |
• Rod mill discharge |
| • Ni acid slurry | • Coarse sand | • Coarse tailings | • Phosphate matrix |
| • Minerals concentrate | • Heavy media | • Dredging | • Bottom/fly ash, lime grinding |
| • Oil sands | • Mineral sands | • Fine tailings | • Phosphoric acid |
| • Coal | • Flotation | • Sugar beets | • Process chemical |
| • Pulp and paper | • FGD | • Waste water | • Aluminum oxide |
