Help CenterPopular Slurry Pump Parts Wear Resistant Spare Parts From China Pump Manufacturer
Related Products
-
Slurry Pump Spare Parts South AfricaUS$ 100 - 400MOQ: 1 Piece -
Slurry Pump Spare Parts in UKUS$ 100 - 400MOQ: 1 Piece
-
Slurry Pump Spare Parts E4147U38 Polyurethane ImpellerUS$ 100 - 400MOQ: 1 Piece
-
Slurry Pump Spare Parts in CanadaUS$ 100 - 400MOQ: 1 Piece
-
Slurry Pump Spare Parts B15017R55 Cover Plate LinerUS$ 100 - 400MOQ: 1 Piece
Centrifugal Slurry pumps are the most popular slurry pumps on the market due to excellent wear life almost without reducing efficiency during the wear cycle.
Competition for slurry pump spare parts always benefits the end users, you can use slurry components diagrams to determine part numbers for your slurry pumps.
Because we are a slurry pump Original Equipment Manufacturer (OEM) with performance curves and original drawings, we know the exacting tolerances and engineering standards required to build and maintain these slurry pumps, and the replacement parts we supply for centrifugal slurry pumps are identical to the parts we put into our slurry pumps.
Slurry pump parts are described by a part number consisting of three segments. First segment describes the relative pump or frame size of the part, second segment describes the part type, third segment describes the material of part.
Slurry pump parts list we recommend should include the above three segments.
Tobee® manufactures quality metal slurry pump parts, elastomer slurry pump parts and polyurethane slurry pump parts fully compatible with warman pumps, and provides value to customers through fair pricing and lead times that are some of the lowest in the market. We stock millions of dollars of pumps and parts globally, all of which are interchangeable with warman pump parts. We maintain a global distribution network that stands ready to serve your process needs.
All parts compatible with the warman slurry pumps have been rigorously reverse engineered using FaroArm® technology with 2D and 3D modeling. First article inspection involves comparison to OEM parts followed by fit testing. All impellers have been performance tested to certify them against OEM performance. Tobee pump manufactures replacement parts for other manufacturers as we do our own: with technical expertise, quality, fair pricing, and product availability for the end-user.
The following list provides the basic part number and description for most slurry pump parts, click on one of basic part numbers or descriptions to get more details, or send mail to us directly to find the replacement parts for your slurry pumps.
| Basic Part Number | Description | Basic Part Number | Description |
| 001 | Adjusting Screw | 080 | Stepped Washer |
| 003 | Base | 081 | Keeper Plate |
| 004 | Bearing Housing | 083 | Throatbush |
| 005 | Bearing Assembly | 085 | Throatbush Cotter |
| 008 | Bearing Sleeve | 089 | Bearing Seal |
| 009 | Bearing | 090 | Shaft Seal |
| 011 | Clamp Washer | 092 | Sump Pump Casing |
| 012 | Clamp Bolt | 102 | Sump Pump Column |
| 013 | Cover Plate | 108 | Piston Ring |
| 015 | Cover Plate Bolt | 109 | Shaft Sleeve O-Ring |
| 017 | Cover Plate Liner | 110 | Volute Liner |
| 018 | Cover Plate Liner – Throatbush |
111 | Packing Ring |
| 019 | Sump Pump Mounting Plate | 112 | Throatbush |
| 021 | Impeller – Two Vanes Open | 114 | Impeller – Six Vanes Open |
| 023 | Cover Plate Liner Stud | 116 | Sump Pump Strainer |
| 024 | End Cover | 117 | Shaft Spacer |
| 025 | End Cover Shim | 118 | Lantern Restrictor |
| 026 | Frame Plate Liner Stud | 122 | Seal Ring |
| 027 | End Cover Set Screw | 124 | Volute Cover Seal |
| 028 | Expeller | 125 | Volute Frame Seal |
| 029 | Expeller Ring | 126 | Gland Clamp Bolt |
| 032 | Frame Plate | 127 | Impeller – Five Vanes Open |
| 034 | Frame Plate Bolt | 130 | Flange |
| 036 | Frame Plate Liner | 131 | Gravel Pump Bowl |
| 039 | Frame Plate Liner Stud | 132 | Discharge Joint Ring |
| 040 | Frame Plate Liner Insert Bolt | 134 | Clamp Ring |
| 041 | Frame Plate Liner Insert | 135 | Clamp Ring |
| 043 | Frame Plate Liner | 137 | Impeller – Three Vanes Closed |
| 044 | Gland | 138 | Grease Cup Adaptor |
| 045 | Gland Bolt | 143 | Volute Seal Holder |
| 046 | Grease Retainer | 144 | Volute Seal Holder Stud |
| 049 | Impeller – Eight Vanes Closed | 145 | Impeller – Four Vanes Closed |
| 051 | Impeller – Two Vanes Open | 147 | Impeller – Five Vanes Closed |
| 052 | Impeller – Three Vanes Open | 154 | Sump Pump Discharge Pipe |
| 053 | Impeller – Eight Vanes Open | 179 | Shaft Sleeve Spacer |
| 056 | Impeller – Four Vanes Open | 184 | Sump Pump Flinger |
| 058 | Impeller – Six Vanes Closed | 190 | Suction Cover |
| 060 | Intake Joint Ring | 191 | Impeller – Eight Vanes Open |
| 061 | Labyrinth Locknut | 204 | Discharge Joint |
| 062 | Labyrinth | 206 | Sump Pump Impeller |
| 063 | Lantern Ring | 217 | Impeller O-Ring |
| 064 | Impeller Sealing O-Ring | 221 | Flange |
| 066 | Motor Support Bolt | 239 | Release Collar |
| 067 | Neck Ring | 241 | Lip Seal Gland |
| 070 | Shaft Key | 290 | Sump Pump Spacer |
| 073 | Shaft | 292 | Door Clamp Plate |
| 075 | Shaft Sleeve | 322 | Sump Pump Suction Pipe |
| 076 | Shaft Sleeve – Long Type | 360 | Mechanical Seal Adaptor |
| 078 | Stuffing Box | 424 | Mechanical Seal Shaft sleeve |
| 079 | Expeller Ring Stud |
Note:
* Tobee® is a registered trademark and does not represent or is not in any way affiliated with Warman® of Weir Minerals Group. All names,numbers, symbols and descriptions are used for reference purpose only and do not imply that any pumps or parts listed is the product of Warman Pumps.
* Tobee® slurry pump spare parts are only interchangeable with Warman® slurry pump spare parts.
* This document is the property of Tobee® Pump and can be neither reproduced nor disclosed to a third party without a written authorization.
