1. Introduction
EUZ01G series single-user ONU is designed for ONU in deferent FTTH solutions by HDV, The carrier-class FTTH application provides date service access.
EUZ01G series adopts high-performance and low-consumption chips, and supports CTC 3.0 interconnection and interworking standard of China Telecom. With the help of NGBN View NMS, it can provide subscribers with abundant services, and totally meet the needs of carrier-class FTTH devices.
EUZ01G series is designed by ZTE chipset
3.Specification:
Item |
Parameter |
|
|
Interface |
PON Interface |
1 EPON optical interface
Meet 1000BASE-PX20+ standard
Symmetric1.25Gbpsupstream/downstream SC single-mode fiber
split ratio:1:64
Transmission distance 20KM |
|
User Ethernet Interface |
1*10/100/1000M auto-negotiation Full/half duplex mode RJ45 connector Auto MDI/MDI-X 100m distance |
|
Power Interface |
12V DC Power supply |
|
|
Performance Parameters |
PON
Optical Parameter |
Wavelength: Tx 1310nm, Rx1490nm Tx Optical Power: -1~4dBm Rx Sensitivity: -27dBm
Saturation Optical Power: -3dBm Connector Type: SC Optical Fiber: 9/125 single-mode fiber |
|
Data Transmission Parameter |
PON Throughput: Downstream 950Mbps; Upstream 930Mbps, 1000Mbps
Packet Loss Ratio: |
|
|
Gateway |
Router mode supports PPPoE/DHCP/ static IP WAN support Route rand Bridge mode WAN support Internet,VoIP,IPTV,TR069 LAN supports DHCP and static IP Support NAT and NAPT Support UPnP |
|
