1. Main Feature:
1.10G,8G,4G,3G,2.5G,1.25G,155m all rate
2.SFP+,XFP,SFP,SFF,CSFP,are customizable
3.Perfectly compatible with famous switch,ZTE HUAWEI etc
4.DDM
5.Choice from Single mode,muli-mode
6.Choice from dual fiber LC,single fiber SC/LC
7.Low power consumption and high sensitivily
8.Programmable of no light alarm function
9.Complying with ROHS standard
10.The working temperature is up from -40c to ~+85c
11.Complying with Class 1 Laser,and the requirements of IEC60825-1
12.The label can be customized according to customer’s requirements
13.The excellent characteristic of overclocking
2.Technical specification
Brand |
OEM, ODM |
Place of origin |
China |
Condition |
New |
Form Factor |
SFP+ |
Wavelength: |
1270/1330nm |
Distance |
20KM |
Data Rate (max) |
10G |
Transmitter |
DFB |
| Receiver | PIN |
| Diagnostics | Digital |
Low End Case Temperature (°C) |
0°C |
|
High End Case Temperature (°C) |
70°C |
Voltage Supply |
3.3v |
Connector |
LC |
Warranty |
2 year |
Compatible with |
ZTE, Huawei, HP etc. |
Application |
Gigabit Ethernet/Fiber Channel |
Time of delivery |
2-4 working days |
Package |
10 pcs/box |
