Micro Ultrasonic Piezoelectric Transducer , Ultrasonic Welding Transducer With 2PCS Grey Ceramics
Description:
Ultrasonic transducers are the heart of ultrasonic products. Electromechanical equipment is especially important. It converts the high-frequency high-voltage power supplied from the electrical box into high-frequency mechanical vibration, and the power output can reach several kilowatts at most, so its stability and power output. It is very important for the operation performance of the whole machine, and it is also the most valuable value in the equipment. It is the key to embody the value of the whole equipment.
Specifications:
| Model | QR-3230-2BZ |
| Frequency | 30khz |
| Output power | 400 watt |
| Joint bolt | M10 |
| Ceramic disc Diameter | 32mm |
| Qty of ceramic discs | 2pcs |
| Capacitance | 3-3.3nf |
| Amplitude | 6 um |
| Application | Plastic welding machine |
Application:
1. Applicable to ultrasonic plastic welding machine, plastic hot plate welding machine and high frequency plastic welding machine for plastic toys, electronics, household appliances, household plastic products, plastic stationery, auto parts and other industries. In addition to the 20KHZ universal series, the ultrasonic plastic welding machine also produces 15KHz series which are specially designed to deal with soft materials such as PP and PE, and need to be connected to the workpiece with large diameter and long width. The power is from 1000W to 4200W, which can meet the requirements of different users.
2. Ultrasonic washing machine for metal mechanical parts, bearings, pneumatic components, electronic devices, optical devices, medical devices, gold and silver jewelry and parts before plating. Power from 100W to 5000W, can also be designed according to user needs for trough, immersion, heating and high-density, low-frequency and other non-standard special models.
3. Ultrasonic lace dissolving machine and ultrasonic kneading machine for textile, garment and craft jewelry industry are a new production process of the industry, which helps the industry to improve the product grade.
4. There are also ultrasonic portable plastic welding machines, ultrasonic plastic hose sealing machines, ultrasonic drilling machines, ultrasonic frequency correction generators, plastic inner page folding machines and organ holders for various industries. Special machines such as molding machines.
