YINYAN manufacturing double planetary disperser machine

Official website:

YINYAN manufacturing double planetary disperser machine

Product Description

YINYAN  manufacturing double planetary disperser machine, it has two frame type mixing shaft called planetary mixing shaft, it is revolution around the center of the mixing tank, and at the same time, it is also rotation around its axis. When the mixing structure is rotating, it takes all the materials from the inner mixing tank, and brings them into the center. After revolution two rings, the mixing structure is rotation a whole ring, after 4 rings, the mixture will be mixed completely, after 38 rings, all the materials could be mixed uniformed.

The basic configurations of double planetary disperser machine:

1. Options of 1 set of scrapers;

2. Options of multi-containers, circulation, cooling, heating, heat preservation, thermal insulation

3. Automatic controlling programs, adjustable by frequency converter

4. Hydraulic lifting or pneumatic lifting

5. Operation under positive pressure or negative pressure

 The double planetary disperser machine has two paddle type mixing agitator, it is running rotation and revolution inside the mixing tank, it makes the high viscous materials be mixed no dead corner.

Working principle of double planetary disperser machine：

Manufacturing double planetary disperser machine consists of reducer, planetary rack, mixing agitator, scrapers, mixing tank, hydraulic system and machine rack. When the planetary structure is running, the low-speed mixing shaft and high-speed dispersing shaft are working rotation and revolution together, it makes the materials under the strong shearing and kneading, to reach a complete uniform result. The planetary structure has scraper design, when it is working, it scrapes on the inner wall of the mixing tank, the mixing tank which is precision processed by large vertical lath machine and polished, then can make sure there is no residual on the inner wall. In additional, options of the scrapers which is equipped on the mixing structure, it can scrape the bottom of the mixing tank. To be ensure the mixing completely and keep the quality of the mixture product.
