CRS-708C flow meter sensor common rail injector tester
------Flow is measured by flow sensor
CRS-708C test bench is our special device to test the performance of high-pressure common rail pump and injector, it can test common rail pump and injector of BOSCH, SIEMENS, DELPHI and DENSO, as well as Piezo injector. It simulates the injection principle of common rail motor completely and the main drive adopts the most advanced speed change by frequency change. High output torque, ultra low noise, rail pressure stable. Oil pump speed, injection pulse width, oil measurement and rail pressure are all controlled by industrial computer by real time. The data is also obtained by computer. 19 inch LCD screen display makes the data more clear. It adopts drive singal modulation, advanced technology, steady performance, precise measurement and convenient operation.
CRS-708C can fulfill the remote assistance by internet and make the maintenance easy to operate.
>>>CHARACTERISTIC
1. Main drive adopts the speed change by frequency change.
2. Controlled by industrial computer in real time, Windows operating system. Fulfill the remote assistance by internet and make the maintenance easy to operate.
3. Flow is measured by flow sensor and displayed on 19 inch LCD .
4. Control the rail pressure by DRV, rail pressure can be tested in real time and controlled automatically, it contains the high-pressure protection function.
5. Oil temperature is controlled by forced-cooling system.
6. Pulse width of the injector drive signal can be adjusted.
7. Protection function of short-circuit.
8. Plexiglass protective door, easy operation, safe protection.
>>>FUNCTION
Common Rail Injector | Common Rail Pump |
1. test brands: BOSCH, SIEMENS, DELPHI, DENSO. | 1. test brands: BOSCH, SIEMENS, DELPHI, DENSO. |
2. test the seal performance of common rail injector. | 2. test the sealing of common rail pump. |
3. test the pre-injection oil quantity of common rail injector. | 3. test the internal pressure of common rail pump. |
4. test the max. oil quantity of common rail injector. | 4. test the proportional electromagnetic valve of common rail pump. |
5. test the min. oil quantity of common rail injector. | 5. test oil transfer pump performance of common rail pump. |
6. test the average oil quantity of common rail injector. | 6. test the flux of common rail pump. |
7. Test the backflow oil quantity of common rail injector. | 7. measure the rail pressure in real time. |
8. Data can be searched, printed and made into database. | |
>>>TECHNICAL PARAMETER
Injection testing frequency | 50~3000 rpm |
Fuel temperature | 40±2°C |
Rail high pressure | 0~1800 bar |
Test oil filtered precision | 5μ |
Input power | 380V/50hz/3phase or 220V/60hz/3phase |
Rotation speed | 0~4000RPM |
Oil tank capacity | 60L |
Flywheel inertia’s moment | 0.8KG.M2 |
Center height | 125MM |
Output power | 11KW |
Overall dimension(MM) | 1900×800×1550 |
Weight | 800 kg. |
we can accept T/T, western union, moneygram, L/C.
Taian Common Rail Industry & Trading CO., LTD
Skype: taiancommonrail
QQ: 1847056723
Tel: 0086-538-6527066
Mobile/Wechat/WhatsApp: +86 15092855661
