Q641TC 3 Pieces Type Pneumatic Ceramic Lined Floating Ball Valve A105 Body
- Shanghai
- T/T L/C
- 30 days
You May Like
-
Class150-Class600 Cast Steel Flange Swing Check Valve
-
API Cast Steel Class 150/ Class 300 Cast Steel Swing Check Valve
-
Cast Steel WCB/CF8/CF8M/CF3/CF3M Flanged Swing Check Valve DN50-DN900
-
NPS2-NPS36 Stainless Steel/Wcb Flange Swing Check Valve H44H
-
API Stainless Steel Flange End Industrial Swing Check Valve for Chemical Industry
-
API Stainless Steel Flange End Industrial Swing Non Return Check Valve for Chemical Industry
Product Details
| Brand Name | FREE-VALVE | Place of Origin | China | |
| Model Number | FRQ641TC | Material | Ceramic | |
| Application | Other, Industry | Structure | Ball | |
| Standard or Nonstandard | Standard | Pressure | Medium Pressure | |
| Power | Other, Electic | Port Size | NPS2 ~NPS8 | |
| Media | Other, Abrasive media | Temperature of Media | Medium Temperature |
Product Description
FREE- VALVE’s Q641TC 3 Pieces type Pneumatic Ceramic Lined Floating Ball Valves are designed with engineering ceramics the engineering ceramics internal parts provide excellent wear resistance, the ceramic ball valves are widely used as an open & close function as well as a throttling control tasks in corrosive medium with abrasive solids content.
Features:
1.The hardness of the ceramic material can be higher than HRC80.
2.Engineering internal parts of ceramic ball valve provide superior protection from corrosive and abrasive medium.
3.Customized actuation types are installed on the ceramic ball valve, the manual lever or gear box, as well as with pneumatic, electric and hydraulic actuators
4.Customized V type ceramic control valve is also available for us.
5.The valve has a floating ball design, the ball is floating, the ball has a defined clearance and is pressed against the downstream seat under the differential pressure to achieve sealing.
Technical Specification
The standards of flange ends | ASME B16.5,GB/T9113 |
Nominal Pressure | 1.0MPa,Class150 |
Size Rang | DN50~DN 200, NPS2 ~NPS8 |
Connection type | Flange |
Working Temperature | ≤200℃ |
Operating Type | Manual, Pneumatic and Electric |
Sealing surface material | Engineering ceramic |
Pressure test | GB/T13927, API598 |
Face to Face | GB/T12221, ASME B16.10 |
Application
FREE- VALVE’s 3 PCS Ceramic Lined Pneumatic Floating Ball Valves are suitable for Silicon Powder, Alumina Powder, Dry Coal Powder, Limestone Slurry, Gypsum Slurry, Plaster, Fly Ash, Mining Ore, Coal Powder Injection, Metallurgical dust, Thermal Power plant FGD , LiCoO2 powder equipment
Price:800-20000USD/set
Origin:China
