4 in 1 4X Zoom 5.0MP Security IR Dome Video Surveillance PTZ CCTV Camera
US$ 59.75 - 59.75
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Brand Name:
Wardmay
Place of Origin:
China
Model Number:
WDM-C6846M
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen,china
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2.0MP 4X Zoom 4 in 1 Hybrid Security IR Bullet Video Surveillance PTZ CCTV CameraUS$ 59.75 - 59.75MOQ: 50 Pieces -
4 in 1 Hybrid 10X Zoom Security IR Bullet Video Surveillance PTZ CCTV Camera From CCTV Cameras SuppliersUS$ 71.65 - 71.65MOQ: 50 Pieces
-
Wdm CCTV 3MP Lnight Vision Integrated Security PTZ IP CameraUS$ 31818 - 31818MOQ: 20 Pieces
-
Wdm New Selling7US$ 150 - 150MOQ: 10 Pieces
-
Wdm-CCTV Hisilision IR Dual Steam H. 264 IP PTZ CameraUS$ 200 - 200MOQ: 10 Pieces
Brand Name
Wardmay
Place of Origin
China
Model Number
WDM-C6846M
Type
Analog Camera
Special Features
Waterproof / Weatherproof
Technology
Pan / Tilt / Zoom
Sensor
CMOS
Style
Dome Camera
4 In 1 4X 2.0/5.0MP Security IR Dome Video Surveillance PTZ CCTV Camera
Features
* HD-AHD Dome Camera, indoor/outdoor
* 1/3'' 2.0M Piexl Sony CMOS
* High definition 2.0/5.0MP,4X Zoom
*OSD menu available, IR Range:50m
*Long distance transmission up to 500 meters over coax cable
* Real time transmission ,loss less video
* Pan/Tilt/Zoom, A-B scan, tour available
Specifications
| Specifications | ||
| Product Name | 4 In 1 4X 2.0/5.0MP Security IR Dome Video Surveillance PTZ CCTV Camera | |
| Model NO. | WDM-C6846S | WDM-C6846M |
| Camera | ||
| Image Sensor | 1/3'' 2.0M piexls CMOS Nextchip 2441 + Sony 323 |
1/2.7'' 5.0M piexls CMOS NVP 2477H + OV05A10 |
| Lens | vari focal lens 4X Zoom =2.8mm~12mm | |
| Image Resolution | HD:1080p/30fps /1080p/25fps | HD:5.0MP/30fps /5.0MP/25fps |
| Effective Pixels | 2.0MP(1920x1080) | 5.0MP(2688x1944) |
| TV System | PAL/NTSC | |
| Electronic Shutter | AUTO/ 1/50 (1/60)-1/100,000sec | |
| Min.illumination | 0.05lux (color), 0.005lux (B/W) | 0.001Lux@F1.2, 0LUX with IR |
| S/N Rate | >=50db | |
| White Balance | Auto | |
| IR-Cut | Auto | |
| IR Control | PWM | |
| IR Range | 50m | |
| Dome | ||
| Horizontal Rotation Range | 350° | |
| Title Rotation Range | 70° | |
| Pan speed | 200°/sec | |
| Tilt Speed | 100°/sec | |
| Ratio Speed | Support | |
| Preset Points | 220 | |
| Guard Tours | 3 Groups | |
| Guard Points | Max.16 points | |
| OSD Menu | Multiple languages for OSD Menu | |
| Park time | 1-60mins setting available | |
| Baud Rate | 1200/2400/4800/9600bps | |
| Video Output | AHD/CVI/TVI/CVBS selectable | |
| Communication mode | UTC&RS485 Coaxial cable | |
| General | ||
| Certification | CE, FCC, RoHS | |
| Operating Temperature | -20ºC - +60ºC | |
| Operating Humidity | ||
| Power supply | DC12V4A | |
| Lightning Protection | Transient voltage 6000V | |
Product Show
