20X Zoom H. 265 1080P Outdoor Waterproof Speed Dome IP PTZ Security Camera
US$ 106.5 - 106.5
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Brand Name:
Wardmay/OEM
Place of Origin:
China
Model Number:
WDM-IP8612B-20X
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen,china
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Mini PTZ Camera 4 in 1 HD 1080P 4X Zoomir Distance Outdoor High Speed Dome IP66 Weatherproof Anti-Explosion PTZ CameraUS$ 45.75 - 45.75MOQ: 50 Pieces -
4 in 1 4X Zoom 5.0MP Security IR Dome Video Surveillance PTZ CCTV CameraUS$ 59.75 - 59.75MOQ: 50 Pieces
-
2.0MP 4X Zoom 4 in 1 Hybrid Security IR Bullet Video Surveillance PTZ CCTV CameraUS$ 59.75 - 59.75MOQ: 50 Pieces
-
4 in 1 Hybrid 10X Zoom Security IR Bullet Video Surveillance PTZ CCTV Camera From CCTV Cameras SuppliersUS$ 71.65 - 71.65MOQ: 50 Pieces
-
Wdm CCTV 3MP Lnight Vision Integrated Security PTZ IP CameraUS$ 31818 - 31818MOQ: 20 Pieces
Brand Name
Wardmay/OEM
Place of Origin
China
Model Number
WDM-IP8612B-20X
Type
IP Camera
Special Features
Waterproof / Weatherproof
Technology
Pan / Tilt / Zoom
Sensor
CMOS
Style
Dome Camera
7" HD-IP IR High Speed dome 1080P IP PTZ Camera
Feature
* 7" Total Metal body construction, IP66 rate protection
* 1/3" CMOS, 2.0 Megapixels, 20X optical zoom
* HD-IP digital interface output, 1080P high definition image
* PWM function, intelligent IR illumination & power consumption is variable, dependant the zoom factor
* IR distance 150M
* Support P2P function,OSD menu is available
* ONVIF2.4 compatible; good compatibility with NVRs like DAHUA , HIKVISION , JUFENG and AXXON , Milestone and so on
Specification:
| Product Name | 7" HD-IP IR High Speed dome 2.0MP IP PTZ Camera | |
| Camera | ||
| Model Number | WDM-IP8612B-20X | |
| Image Sensor | 1/3'' 2.0M piexls CMOS Hi3516E + Sensor Sony 323 | |
| Effective Pixels | 2.0MP(1920x1080) | |
| Min. Illumination | Color; 0.05Lux@(F1.6, AGC ON) ; 0.01Lux@(F1.6, AGC ON) | |
| Zoom | 20X optical zoom, f=4.7-94mm, D/N( ICR-Cut) ,F1.6~F1.8 | |
| Day/Night | Day / Night / External control (IR Cut Filter) | |
| SNR | ≥50dB(AGC OFF) | |
| WDR | Digital WDR≥70dB | |
| AGC | Auto / Manual | |
| White balance | Auto/Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp | |
| Digital noise Reduction | DNR, 3DNR | |
| Network | ||
| Video Compression | H.265/H.264 Main Profile/M-JPEG | |
| Max Image Size | 1920x1080@30fps | |
| Streams | Dual streams | |
| Frame Rate | Main stream: 1920*1080, 1280*960, 1280*720,720*576, 640*480 | |
| Sub-stream: 640*480,480*360, 352*288, 320*240, 176*144 | ||
| Bitrate | CBR/VBR, bitrate; 32Kbps~10Mbps variable | |
| Audio Compression | G711, PCM | |
| P2P | Android / IOS | |
| Protocols | TCP/IP,HTTP, NTP,IGMP, DHCP,UDP,SMTP,RTP,RTSP,ARP,DDNS,DNS,P2P | |
| Motion detect | Support | |
| Privacy Zone Masking | Support | |
| Onvif | Onvif 2.4 | |
| IR parameters | ||
| Night vision distance | 240M | |
| Dome Features | ||
| Pan Range | 360° continued rotation | |
| Tilt Range | 0~90°(Auto Flip) | |
| Manual pan speed | 0.02~200°/S (1-64 degree variable) | |
| Manual tilt speed | 0.02~120°/S (1-64 degree variable) | |
| Actual preset Accuracy | ±0.10° | |
| Preset points | 220 | |
| Operation OSD language | Chinese /English | |
| General | ||
| Certification | RoHs ,CE,FCC,IP66 | |
| Work temperature | External-35Celsius degree~65Celsius degree | |
| Work Humidity | 0%~95% (Non condensing) | |
| Temperature control | Intelligent control | |
| Power | DC 12V | |
| Consumption | ≤ 20W | |
| Lightning Protection | Transient Voltage 6000V | |
