GC Boiler Feed Water Multistage Pump

GC Boiler Feed Water Multistage Pump thumbnail-1
GC Boiler Feed Water Multistage Pump thumbnail-2
GC Boiler Feed Water Multistage Pump thumbnail-3
GC Boiler Feed Water Multistage Pump thumbnail-4
GC Boiler Feed Water Multistage Pump thumbnail-5
GC Boiler Feed Water Multistage Pump photo-1
GC Boiler Feed Water Multistage Pump photo-2
GC Boiler Feed Water Multistage Pump photo-3
GC Boiler Feed Water Multistage Pump photo-4
GC Boiler Feed Water Multistage Pump photo-5
US$ 650 - 10000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
kenshine-pump
Place of Origin:
China
Model Number:
1.5GC
Contact Supplier Request Quote Chat Now
Kenshine-pump
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
20 days

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name kenshine-pump
Place of Origin China
Model Number 1.5GC
Application Other, feed water ,booster pump
Fuel Other, electric motor
Power Electric
Usage Water
Theory Centrifugal Pump
Standard or Nonstandard Standard
Structure Multistage Pump
Pressure High Pressure

GC boiler feed water multistage pump is horizontal single-suction multistage segmental-type centrifugal pump. GC pump is mainly used for boiler feed water, so also known as boiler feed water pump. This series of boiler feed pumps are suitable for conveying clean water with temperature less than 110°C or other non-corrosive liquids with physical and chemical properties similar to water. They are widely used for boiler feed water of industrial and mining enterprises and public institutions and urban domestic water supply.

GC pumps are especially suitable for boiler feed water. Also it can be widely used in pressure vessel water supply, hot water circulation, high-rise building water supply, irrigation, fire pressurization, rinse with water, food, brewing, medicine, chemical industry, aquaculture, environmental protection, such as the chemical technological process and form a complete set of machine tool industry, as the power equipment of water supply and drainage.

Features of GC multistage pump:

GC type pump is multi-stage segmental type, 1-1/2 GC - 4 GC four types have inlet and outlet on the inlet water line and outlet water line respectively and are all vertical. the head can be used according to need and increase or decrease the pump series. The head can be adjusted according to the stages of impellers.

The main parts of GC pump are shaft, shaft sleeve, inlet, impeller, seal ring, middle section, outlet section, balance ring, balance plate, tail cover etc.

Model Flow Head Speed Efficiency Power（KW）
(mз/h） （m） （r/min） （%） Shaft Motor
1.5GC-5×2  6 46 2950 38 2 3
1.5GC-5×3  6 49 2950 38 3 4
1.5GC-5×4  6 92 2950 38 4 5.5
1.5GC-5×5  6 115 2950 38 5 7.5
1.5GC-5×6  6 138 2950 38 6 7.5
1.5GC-5×7  6 161 2950 38 7 7.5
1.5GC-5×8  6 184 2950 38 8 11
1.5GC-5×9  6 207 2950 38 9 11
2GC-5×2  10 64 2950 39.6 4.4 7.5
2GC-5×3  10 96 2950 39.6 6.6 11
2GC-5×4  10 128 2950 39.6 8.8 15
2GC-5×5  10 160 2950 39.6 11 15
2GC-5×6  10 192 2950 39.6 13.2 18.5
2GC-5×7  10 224 2950 39.6 15.4 22
2GC-5×8  10 256 2950 39.6 17.6 30
2GC-5×9  10 288 2950 39.6 19.8 7.5
2.5GC-6×2  15 62 2950 43.7 5.8 11
20 54 2950 47.4 6.2 11
2.5GC-6×3  15 93 2950 43.7 8.7 15
20 81 2950 47.4 9.3 15
2.5GC-6×4  15 124 2950 43.7 11.6 22
20 108 2950 47.4 12.4 22
2.5GC-6×5  15 155 2950 43.7 14.5 22
20 135 2950 47.4 15.5 22
2.5GC-6×6  15 186 2950 43.7 17.4 30
20 162 2950 47.4 18.6 30
2.5GC-6×7  15 217 2950 43.7 20.2 30
20 189 2950 47.4 21.7 30
2.5GC-6×8  15 248 2950 43.7 23.2 37
20 216 2950 47.4 24.8 37
2.5GC-6×9  15 279 2950 43.7 26.1 22
20 243 2950 47.4 27.9 22
4GC-8×2  30 86 2950 51 13.8 30
45 82 2950 60 16.8 30
55 76 2950 62.5 18.1 30
4GC-8×3  30 129 2950 51 20.7 37
45 123 2950 60 25.2 37
55 114 2950 62.5 27.2 37
4GC-8×4  30 172 2950 51 27.6 55
45 164 2950 60 27.6 55
55 152 2950 62.5 36.2 55
4GC-8×5  30 215 2950 51 34.5 55
45 205 2950 60 42 55
55 190 2950 62.5 45.3 55
4GC-8×6  30 258 2950 51 41.4 75
45 246 2950 60 50.4 75
55 228 2950 62.5 54.1 75
4GC-8×7  30 301 2950 51 48.2 75
45 287 2950 60 58.8 75
55 266 2950 62.5 63.4 75
4GC-8×8  30 344 2950 51 55 100
45 328 2950 60 67 100
55 304 2950 62.5 73 100
4GC-8×9  30 387 2950 51 62 100
45 369 2950 60 75.5 100
55 342 2950 62.5 82 100
4GC-8×10  30 430 2950 51 69 -
45 410 2950 60 84 -
55 380 2950 62.5 91 -
