Help Center40-400mesh Wire Net Weaving MachineSKZWJ-2100 Betty@jxwiremeshmachine.com
Related Products
-
0.025-0.35mm Wire Net Weaving Machine SKZWJ-1600NegotiableMOQ: 1 Set -
Numerical Control Wire Net Weaving Machine SKZWJ-1300NegotiableMOQ: 1 Set
-
5.5KW Power Heavy-duty Metal Wire Net Weaving Machine JL2200D-3J/Z Betty@jxwiremeshmachine.comNegotiableMOQ: 1 Set
-
5.5KW Power Heavy-duty Metal Wire Net Weaving Machine JL2200D-3J/Z Betty@jxwiremeshmachine.comNegotiableMOQ: 1 Set
-
Heavy Duty Water Jet Loom/shuttleless Loom/shuttleless Weaving LoomNegotiableMOQ: 1 Set
Product Details：
Model Number： |
SKZWJ-2100 |
Power(W)： |
2.2KW |
|
Dimension(L*W*H)： |
2.6m*4.2m*1.4m |
Wire Diameter： |
0.025-0.35mm |
|
Mesh Size： |
40-400mesh/inch |
Mesh Width： |
2100 |
|
Machine Type： |
Numerical Control |
Beating-up frequency: |
120r/min |
|
Condition： |
New |
Color： |
Requirement |
|
Production Capacity： |
100sets / Month |
Packaging Details： |
wooden case |
|
Place of Origin： |
Hebei, China （Mainland) |
Port： |
Xingang Tianjin |
|
After-sales Service Provided： |
Engineers Available To Service Oversea |
|||
Function introduction：
PLG programmable control system is adopted in this machine, which controls winding and let off by servo motor, realizes automatic adjustment of mesh tension, improves mesh accuracy, and weaves fabrics with 40-400 mesh standard wire diameter more accurately; makes the speed of the loom reach 120r / min, and improves efficiency by 71%; digital control is realized by mesh adjustment and tension setting, which makes the mesh and tension adjustment simple and accurate; infinite winding is adopted Net mode and digital display of the length of the net can shorten the auxiliary time of weaving and greatly improve the production efficiency.
Characteristics:
1, Adaptability to metal wires:Adapt to various imported and domestic metal wires.
2, Large adjust range:The metal wire screen can be woven out mesh but also special kinds up to 2600 mesh,such as plain weaving,twill weaving,mat weaving and taper contrast high density screen weaving,etc,and have advantage over products of other machines.
3, The machine adopts technique of shuttless and straightway weft leading,automatic warp feeding and winding.Sheddings are small,and surfaces of woven screens are smooth,and there is not any bright spot,bright trace and other defects on fine screens.The machine can make high -grade in the standard of GB/T 5330-2003.
4, Lower center of gravity,good stability,low noise and energy consumption,high effciency.
5, Rational design,simple construction,easy to operate and maintain.
The technical parameters are shown in the Table below.
TYPE |
SKZWJ-1300 |
SKZWJ-1600 |
SKZWJ-2100 |
Mesh Size |
40-400mesh/inch |
40-400mesh/inch |
40-400mesh/inch |
Wire Diameter |
0.025-0.35mm |
0.025-0.35mm |
0.025-0.35mm |
Bating-up Frequency |
120r/min |
120r/min |
120r/min |
Mesh Width |
1300mm |
1600mm |
2100mm |
Motor Power |
2.2kw |
2.2kw |
2.2kw |
Over Size |
2.6m*3.4m*1.4m |
2.6m*3.7m*1.4m |
2.6m*4.2m*1.4m |
Our Services：
Provide installation and commissioning services abroad, one year warranty, the warranty period there were problems, at any time to repair.
Packaging & Shipping：
The control box is wooden case package, other small parts the bag package, the big part is waterproof film package, if you need others we can do also.
FAQ:
Guarantee: one year, during this year, any broken parts caused by the quality, we can offer free,after this year can offer with the lowest cost.
Install and training:offer video and operation manual, if need engineer oversea service, the customer need to pay the round air tickets, hotel, food and also the salary USD100 per engineer one day.
Delivery time: 20days after advance payment
Payment terms: T/TLCWU/MG
Packing: waterproof material,control box: wooden case
