Introduction
Ball mill for lead oxide is used to grind many kinds of mine and other materials, or to select the mine, which is widely used in building material, chemical industry, etc. There are two ways of grinding: the dry process and the wet process. Ball Grinding Miller can be divided into tabular type and flowing type according to different forms of discharging material.
Working principle
This Ball Grinding Mill is horizontal type and tubular running device, has two warehouses. This machine is grid type and its outside runs along gear. The material enters spirally and evenly the first warehouse of the milling machine along the input material hollow axis by input material device. In this warehouse, there is a ladder scaleboard or ripple scaleboard, and different specification steel balls are installed on the scaleboard, when the barrel body rotates and then produces centrifugal force. Meanwhile, the steel ball is carried to some height and falls to make the material grinding and striking. After grinded coarsely in the first warehouse, the material then enters into the second warehouse for regrinding with the steel ball and scaleboard. In the end, the powder is discharged by output material board andthe end products are completed.
Characteristic
1. The hollow axis adopts the cast steel and the lining can replace , the rotating big gear processes in the way of casting rolling gear;
2. The barrel body is wearable well and bears wearable scaleboard;
3. This machine run steadily and works reliably;
4. Liner of ball mill is made of high-quality wear resistant material with high strength, wear resistance and long working life.
Technical Parameter
Model |
Rotary Speed r/min |
Ball Load t |
Feed Size mm |
Discharge Size mm |
Output t/h |
Power kw |
Weight t |
Φ900×1800 |
36-38 |
1.5 |
≤20 |
0.075-0.89 |
0.65-2 |
18.5 |
4.6 |
Φ900×3000 |
36 |
2.7 |
≤20 |
0.075-0.8 |
1.1-3.5 |
22 |
5.6 |
Φ1200×2400 |
36 |
3 |
≤25 |
0.075-0.6 |
1.5-4.8 |
30 |
12 |
Φ1200×3000 |
36 |
3.5 |
≤25 |
0.074-0.4 |
1.6-5 |
37 |
12.8 |
Φ1200×4500 |
32.4 |
5 |
≤25 |
0.074-0.4 |
1.6-5.8 |
55 |
13.8 |
Φ1500×3000 |
29.7 |
7.5 |
≤25 |
0.074-0.4 |
2-5 |
75 |
15.6 |
Φ1500×4500 |
27 |
11 |
≤25 |
0.074-0.4 |
3-6 |
110 |
21 |
Φ1500×5700 |
28 |
12 |
≤25 |
0.074-0.4 |
3.5-6 |
130 |
24.7 |
