GUS Automated Systems SMT Inspection Machine AOI Optical Inspection Machine
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
30 days
Related Products
-
GUS Automatic SMT Assembly Line PCB Cassette Loader for SMT Line LoadersNegotiableMOQ: 1 Piece -
GUS SMT Connection Conveyor PCB Conveyor Assembly Line With Fan CoolingNegotiableMOQ: 1 Piece
-
GUS Hot Selling SMT Assembly Production Line Conveyor Automatic PCB Magazine Loader With Low PriceNegotiableMOQ: 1 Piece
-
GUS Cost-effective SMT Automatic Wave Soldering Machine Made in ChinaNegotiableMOQ: 1 Piece
-
GUS SMT PCB Assembly Line With Fan Conveyor Wave Soldering and Unloading MachineNegotiableMOQ: 1 Piece
Brand Name
GUS
NYPL-910 Off-line AOI Testing Equipment
Product characteristics:
1.Suitable for AOI inspection of high-end electronic
products in SMT production line, minimum inspection of 01005 parts;
2.Suitable for accurate and stable AOI detection of FPC soft board;
3.Intelligent Camera Bar Code Recognition System(one-dimensional code and two-dimensional code can be selected);
3.Professional SPC report analysis system, monitoring and analyzing product quality status at all times;
4.The combination of remote programming and debugging control functions makes the software more powerful.
5.PCB board A and B surface automatic recognition.
NYPL-910 offline configuration parameters
| category | project | Specifications | |
| visual identification system | Discriminant method | Color image contrast | |
| Camera | CCD color camera, resolution: 10 microns / point, | ||
| light source | RGB+ white four-color ring LED unique light source | ||
|
Image Speed |
0201 Chip | > 8ms | |
| Processing time per screen | |||
| Test content | Solder paste printing | Missing, skewing, even tin, Shaoxi, poly tin, open circuit, pollution | |
| Part defect | Missing parts, offset, skew, tombstone, side stand, flip, polarity reverse, wrong piece, broken | ||
| Solder joint defect | Tindo, tin less, even tin, solder joint | ||
| Anti-static measures | Anti-static socket, anti-static ring | ||
| computer system | PCB size |
Minimum: 25mm × 25mm, Maximum: 380mm × 480mm (Can be customized according to customer specific requirements) |
|
| PCB thickness | 0.5mm~2.5mm | ||
| PCB warpage | |||
| Part height | |||
| Minimum part | 01005Chip | ||
| X, Y platform | Drive device | AC servo motor system | |
| Precise positioning | |||
| Moving speed | 700mm/s | ||
| Software system | operating system | Support Windows XP, Windows 2000, Windows 2003 | |
| Pre-installed with Windows XP | |||
|
Identification control System |
Characteristics | Statistical shape modeling, learning OK samples, automatically creating standard images, identifying data and error thresholds | |
| operating | Graphical programming, self-contained component library, automatically generate detection frame according to component shape selection criteria, precise automatic positioning, micro-level fine-tuning, fast process | ||
| Mark | Points | 0~2 common Mark points can be selected | |
| Recognition speed | 0.35s/pcs | ||
| Control System | Industrial computer |
E5500,Dual Core Processor 3.0G,DDR 4G,SSD 60G |
|
| display | 22-inch LED widescreen display | ||
| Other parameters | Mechanical Dimensions (L*W*H) | 860mm * 960mm * 1560mm | |
| weight | 500Kg | ||
| power supply | AC220V/-10%,50/60Hz,600W | ||
| Remarks | The above is the standard configuration, each parameter can be customized according to the customer. | ||
