Help CenterYBYB Portable Electric Barrel Pump Drum Pump Diesel Oil Kerosene Oil Transfer Pump
Related Products
-
FQW Pneumatic Submersible Sewage PumpUS$ 500 - 800MOQ: 1 Set -
WQ,QW Submersible Sewage Pump Non Clogging PumpUS$ 650 - 10000MOQ: 1 Set
-
FY Pneumatic Slurry Pump Pulp Pump Drum PumpUS$ 300 - 3000MOQ: 1 Set
-
WQ Submersible Wastewater PumpUS$ 300 - 10000MOQ: 1 Set
-
WQ,QW Submersible Sewage Non Blocking PumpUS$ 300 - 10000MOQ: 1 Set
YBYB electric barrel pump, drum pump, submerged pump, diesel oil transfer pump, hydraulic oil pump, Kerosene oil explosion proof pump,
YBYB portable flameproof single-phase oil pumps, oil drum pump, electric barrel pump, submerged pump, explosion-proof oil drum pump is applicable to the condition with explosive power level no higher than B and ignition temperature classes not under T4 group of flammable gas or vapor and air form explosive mixture of ground. YBYB explosion proof barrel is inserted into the standard oil barrel of 200L to transport gasoline, kerosene, diesel oil, engine oil, edible oil and other corrosive liquid.
SB Series Electric Transfer Pump is a kind of barrel pump, it is easy to use and maintenance, and high efficiency. SB Series Electric Transfer Pump can put the tube into the drum to pump liquid. It is widely used to transfer acid, alkali, oil and drink, and some low-viscosity liquid in industry of chemical plant, petrochemical industry, Fine Chemicals, dye chemical, water treatment and food section etc. SB Series Electric Transfer Pump is also an ideal oil transfer tool in oil station, oil tanker, ship, truck etc.
According to different liquid, the pump tube material can be aluminum alloy or stainless steel. The electric motor can be explosion proof motor or standard normal motor. There are 3 series and 12 models according to different material and motor type.
| pump | Flow | Flow | Head | Speed | power | inlet | outlet | Material | Weight |
| model | m3/h | L/min | m | r/min | Kw | mm | mm | tube | Kg |
| SB-3-316L | 9 | 150 | 10 | 12000 | 0.88 | 50 | 25 | SS316L | 10.5 |
| SB-3-RPP | 9 | 150 | 10 | 12000 | 0.88 | 50 | 25 | PP | 6 |
| SB-5-PP-1 | 1.2 | 20 | 3 | 5600 | 0.12 | 50 | 25 | PP | 5.1 |
| SB-5-SS-1 | 1.2 | 20 | 3 | 5600 | 0.12 | 50 | 25 | SS | 5.8 |
| SB-9-PP-1 | 3 | 50 | 4 | 5600 | 0.37 | 50 | 25 | PP | 8 |
| SB-9-PP-2 | 3 | 50 | 4 | 5600 | 0.37 | 50 | 25 | PP | 8 |
| SB-9-SS-1 | 3 | 50 | 3.5 | 5600 | 0.37 | 50 | 25 | SS | 9.3 |
| SB-9-SS-2 | 1.56 | 26 | 7 | 5600 | 0.37 | 50 | 25 | SS | 9.4 |
| SB-3-SS-3 | 2.4 | 40 | 4 | 5600 | 0.37 | 50 | 25 | SS | 9.5 |
| YBYB-40 | 2.4 | 40 | 3 | 2850 | 0.12 | 55 | 20 | Aluminum alloy | 7 |
| YBYB-40PG | 3.6 | 60 | 6 | 2850 | 0.18 | 55 | 20 | SS | 9.5 |
| YBYB-40P | 2.4 | 40 | 3 | 2850 | 0.12 | 55 | 20 | SS | 8 |
Send Inquiry to This Supplier
