pneumatic well drilling rig large crawler drilling equipment percussion rotary drilling machine simple operation
31200 - 31500
/ Set
1 Set(Min.Order)
- 100 Set / Sets per Month
- QINGDAO
- T/T L/C
- 7 days
You May Like
-
crawler pneumatic well drilling rig steel chain track impact drill machine is suitable for industrial and civilian drilling
-
Manufacturer direct selling crawler drilling machine drilling diameter 140-325mm 85KW high power fast drilling machine
-
400m shallow hole drilling machine crawler type full hydraulic well drilling rig large hole diameter
-
The backpack rig is light weight and easy to carry the imported power geological survey rig
-
Backpack rig vertical giant BXZ-2Lcore exploration rig can be operated by a single person and can hit 30 meters
-
Huaxia Master BXZ-2 backpack sampling rig 20 meters handheld geological exploration equipment kohler engine
Product Details
| Brand Name | Huaxia master | Place of Origin | China | |
| Model Number | FY-200 | Type | Other, percussion rotary drill | |
| Certification | ISO9001 | After-sales Service Provided | Overseas service center available | |
| Warranty | 6 months | Weight | 4.6T | |
| Dimension(L*W*H) | 3800*1600*2450 | Power Type | Electric | |
| Usage | Water Well | Condition | New | |
| Power(W) | 65kw |
Product Description
FY200 crawler pneumatic water well drilling rig
1. The applications of FY200 crawler pneumatic water well drilling rig
· civil engineering drilling
· geothermal drilling
· drilling with large diameter
· deep drilling footage
· fast, flexible and efficient.
2.The specifications of FY200 crawler pneumatic water well drilling rig
Model | FY200 | |
Gross weight | t | 4.6 |
Dimension | mm | 3800*1600*2450 |
Aperture | mm | 140-325 |
Drilling depth | m | 200 |
Feed stroke | mm | 3000 |
Travel speed | km/h | 2.5 |
Grade ability | max. | 30° |
Rising height from ground | mm | 250 |
Wind pressure | mpa | 1.7-3.0 |
Air consumption | m³/min | 17-35 |
Engine power | kw | 65 |
Rotary speed | rpm | 50-70 |
Rotation torque | n.m | 5000-6500 |
