Help CenterSupply Portable Core Sampling Rig With Standard 20 m Drill Pipe Small Geological Exploration Rig for Operation by Two Pers
Related Products
-
The Motor Power Sampling Rig is a Good Assistant for Geological Exploration it Weighs 90kg and Can be DisassembledUS$ 2030 - 2100MOQ: 1 Set -
Supply Hand Pull Rope Start Gasoline Engine Power Portable Exploration Drill With High Pressure Fresh Water Pump Small Core RigUS$ 2870 - 2900MOQ: 1 Set
-
Drilling Hole is Not Difficult Engineering Construction Exploration Drilling Machine up the Hill Construction is ConvenientUS$ 2870 - 2900MOQ: 1 Set
-
Huaxia Master Specialized by Geological Inspection Sampling Drill Compact Structure Core Drill Rig Small VolumeUS$ 3380 - 3500MOQ: 1 Set
-
Portable Core Drill Equipped With Hand Hosit Soil and Rock Detection Sampling Rig Can be Used for Field ConstructionUS$ 3710 - 3800MOQ: 1 Set
QZ-2A three phase electric sampling drilling rig
1.Brief introduction of QZ-2A three phase electric sampling drilling rig
QZ-2A is a three phase electric sampling drilling rig , produced by Shandong Master Machinery Group Co.,Ltd. It is suitable for industrial and civil buildings, bridges, railways, roads, utilities and other sectors of the geological exploration.
2. Technical parameters of QZ-2A three phase electric sampling drilling rig
QZ-2A three phase electric sampling drilling rig | |
Borehole diameter (mm) |
32-91 |
|
Drilling depth（m） |
soilφ91：10-15m stoneφ91：5-10m stoneφ75：10-15m stoneφ60：15-20m stoneφ46：20-25m |
Drilling pipe diameter (mm) |
28 |
Rotate speed（r/min） |
185-380 |
Torque（n.m） |
80 |
Power（kw） |
3 |
Dimension（l*w*h） |
600*450*1900 |
Weight（kg） |
95 |
3. Configuration list of QZ-2A three phase electric sampling drilling rig
Item |
Parameter |
Unit |
Quantity |
Three phase electric sampling drilling rig |
QZ-2A |
platform |
1 |
Drilling pipe |
28*1500 |
pc |
6 |
Drilling pipe |
28*800 |
pc |
8 |
Drilling joint |
35 |
pc |
14 |
Reducing nipple |
45/35 |
pc |
1 |
Core barrel |
45*800 |
pc |
1 |
Alloy bit |
46 |
pc |
1 |
Reducing nipple |
58/35 |
pc |
1 |
Core barrel |
58*800 |
pc |
1 |
Alloy bit |
60 |
pc |
1 |
Three-wing bit |
0 |
pc |
1 |
Safety clamp |
hold |
1 |
|
Water seal |
Y30*50*10 |
pc |
4 |
Oil seal |
17*50*10 |
pc |
2 |
Control wheel |
set |
1 |
If you need a wooden base, a high pressure pump and a high pressure water pipe, please specify.
