Help CenterXyx-3 Traveling Core Drilling Rig Engineering Water Well Drilling Rig Road Survey Engineering Drilling Machine
Related Products
-
Shandong Supplies Xy-3 Hydraulic Well Drilling Rig 6 00 Type Drilling Rig for Geological Exploration Core DrillingUS$ 14350 - 15000MOQ: 1 Set -
Xy-3 600m Hydraulic Geological Drill , Prospecting Drill, Coring Drill Rig Domestic Deep Well Drilling RigUS$ 14350 - 15000MOQ: 1 Set
-
Xy-200 Water Well Drilling Machine 200 Meters Domestic Water Well Drilling Machine Coring Rig High Quality Drilling MachineUS$ 6920 - 6950MOQ: 1 Set
-
Xy-200 Drilling Machine for Geological Exploration Core Sampling Drilling Machine 200 m Shallow Hole Drilling Well Drill Machine View Larger Image Xy-200 Drilling Machine for Geological Exploration Core Sampling Drilling Machine 200 m Shallow Hole DrillinUS$ 6920 - 6950MOQ: 1 Set
-
Family Hydraulic Well Drilling Machine Xy-200 Type Water Well Drilling Rig Diesel Power Drilling RigUS$ 6920 - 6950MOQ: 1 Set
Parameters of XYX-3 wheeled hydraulic water well drilling rig
Drilling hole depth |
100/ 250 / 300/ 600 m |
Maximum opening diameter |
300 / 200 /150 / 75mm |
Max open hole caliber |
300mm |
Final hole diameter |
75mm |
Drill pipe |
60mm |
Borehole inclination |
90°-65° |
A vertical scroll of painting | |
Vertical rotation speed of vertical axis 30-1050r/min | |
Vertical reversal speed |
29-137r/min |
Vertical axis stroke |
560mm |
Diameter of shaft inner hole |
96mm |
Vertical axis lifting capacity |
60kn |
Main hoist (hydraulic drive) | |
Single rope lifting speed |
0-45m/min |
Wire rope diameter |
14mm |
Band width |
90mm |
Drum diameter |
300mm |
Reel capacity |
30m |
Maximum lifting capacity of single rope |
40kn |
Auxiliary hoist (hydraulic drive) | |
Drum diameter |
140mm |
Diameter of steel wire |
6mm |
Reel capacity |
450m |
Mud pump | |
Mud pump |
BW-250 Horizontal three cylinder |
Flow |
250 l/min |
Working pressure |
7mpa |
Inlet diameter |
75mm |
Outlet diameter |
50mm |
Gear oil pump | |
Double oil pump |
CBF-F63/25 |
Front-end flow pressure |
63 l/min 20mpa |
Backend flow pressure |
25 l/min 20mpa |
Rig power | |
Diesel engine |
FAW Xichai 4 cylinder |
Electric machinery |
Y180L-4 22KW |
Wheeled chassis | |
Bearing capacity of wheel chassis |
3.5t |
Wheel chassis length |
2.6m |
Wheel chassis width |
2m |
Wheel chassis height |
0.6m |
