Help CenterShandong Supplies Xy-3 Hydraulic Well Drilling Rig 6 00 Type Drilling Rig for Geological Exploration Core Drilling
Related Products
-
Xy-3 600m Hydraulic Geological Drill , Prospecting Drill, Coring Drill Rig Domestic Deep Well Drilling RigUS$ 14350 - 15000MOQ: 1 Set -
Xy-200 Water Well Drilling Machine 200 Meters Domestic Water Well Drilling Machine Coring Rig High Quality Drilling MachineUS$ 6920 - 6950MOQ: 1 Set
-
Xy-200 Drilling Machine for Geological Exploration Core Sampling Drilling Machine 200 m Shallow Hole Drilling Well Drill Machine View Larger Image Xy-200 Drilling Machine for Geological Exploration Core Sampling Drilling Machine 200 m Shallow Hole DrillinUS$ 6920 - 6950MOQ: 1 Set
-
Family Hydraulic Well Drilling Machine Xy-200 Type Water Well Drilling Rig Diesel Power Drilling RigUS$ 6920 - 6950MOQ: 1 Set
-
HuaxiaMaster Xy-180 Hydrologic Drilling Rig Geological Exploration Rock Sampling Convenient Fast Genuine SaleUS$ 6750 - 6900MOQ: 1 Set
Parameters of XY-3 hydraulic water well drilling rig
XY-3 water well drilling rig | |
Water well drilling depth |
600m |
Borehole diameter |
300-75mm |
Max open hole caliber |
300mm |
End hole caliber |
75mm |
Drilling rod diameter |
60 |
Drilling angle |
90°-65° |
Spindle | |
spindle speed |
30-1050r/min |
Spindle stroke |
29-137r/min |
Spindle stroke |
60mm |
Spindle inner diameter |
96mm |
Lifting capacity |
6000kg |
Hoist | |
Max.single line lifting speed |
0.5-1.9m/s |
Wirerope caliber |
12.5mm |
Max.single line lifting capacity |
4000kg |
Reel diameter |
300mm |
Wirerope length |
50m |
Maximum lifting capacity of single rope |
3000kg |
Mud pump | |
Type |
Horizontal three cylinder BW-250 |
Displacement |
250l/min |
Work pressure |
80kg/cm² |
Water inlet pipe diameter |
75mm |
Water outlet pipe diameter |
50mm |
Gear oil pump | |
Duplex gear oil pump |
CBF-F63/25 |
Front displacement, pressure |
63l/min 20mpa |
Water outlet pipe diameter |
25l/min 20mpa |
Power | |
Diesel engine |
39kw |
Electric machinery |
22kw |
Weight size | |
Drill weight |
1800kg |
Shape size |
2500*900*1800mm |
