FUNCTION INTRODUCTION |
| Induction revolving, constant temperature indoor, emergency stop, button for disabled pass slowly, safety and fire protection, motor lock, door leaf stop position, speed adjustment, manual/automatic switch. |
TECHNICAL DATA |
|
Supply power: AC 220V±10%，50/60Hz Power consumption: motor 200-350W, light 200-400W Intelligent computer control Multilevel control system, frequency control drive |
STANDARD CONFIGURATION |
|
1.Glass Door leaf and exhibition box are 6/8mm transparent tempered glasses, curved wall is 10mm tempered glasses (or 5+5mm arc safety laminated glass).
2. Drive device 220V±10%, 50/60Hz, 0.25-0.35KW
3. Central control computer PLC programmable logic control system.
4. Revolving pattern The variable-frequency speed adjustment system starts, revolves, and stops smoothly and safely.
5. Sensor Microwave motion sensors.
6. Prevent pinching sensor located at the upright column at entrance right.
7. Avoid to knock at the door leaf Installed a sensor in the rubber strip at the bottom of the leaf.
8. Emergency stop button Installed on the upright column at entrance right.
9. Button for the disabled Use for disabled people pass slowly.
10. Mechanical lock Used for locking the door at night
11. 6-9 pieces laser ceiling lamp
12. Combination operation panelFunctional combination operation panel facilitate function setting. |
