Explosion proof air conditioning Industrial air conditioning Cold and warm explosion-proof air conditioning

1. Explosion-proof air conditioner adopts international famous compressor, running smoothly and reliably, saving electricity and having long service life;

2, explosion-proof air conditioning using efficient multi-wing radiator, refrigerant through contact with the air more fully, can greatly improve the cooling and heating effect of air conditioning;

3, explosion-proof air conditioning automatic operation mode, multiple protection, fault self-diagnosis, intelligent cream, low temperature start, timing function.

4. Explosion-proof air conditioner has beautiful appearance, convenient operation, space saving and easy installation;

5. Climate types of explosion-proof air conditioning: T1 (-7-43℃), T3 (-7-55℃);

6. The explosion-proof air-conditioning power supply is 220V/50Hz, 110V/60Hz, 220V/60Hz;

7, explosion-proof air conditioning latest explosion-proof structure design, easy installation, safe and reliable, quality assurance;

8. Explosion-proof mark: Exdmib II BT4, Exdmia II CT4;

9. Explosion-proof air conditioner is applicable to the inflammable and explosive industries such as petroleum, chemical industry, military industry, pharmaceutical industry and storage;

10, explosion-proof air conditioning varieties are complete, there are high temperature type, low temperature type, Marine, vehicle-mounted, well type and other varieties, to meet users in different occasions.

Technical parameters of 1P wall-mounted explosion-proof air conditioner:

Model: BSTF - 25 / F

Climate type: T1

Protection against electric shock: class I

Refrigerating capacity/heat produced: 2,500/2,750

Rated power of refrigeration/heating W: 830/850

Voltage V/ frequency Hz:110/60 220/50 208/60

Circulating air volume m3/h: 500

Refrigerant and injection quantity kg: R22/0.6

Noise indoor/outdoor dB(A):30/50

Ambient temperature: -7~43

Waterproof grade: IPX4

Indoor/outdoor width * height * depth: 750x250x195; 700 x535x235

Weight (indoor/outdoor) : 15/45

Flameproof mark: ExdeibmbIIc T4 Gb

Model project BSTF (R) BSTF - 6.0-5.0 / F/F (R)/F (R) BSTF BSTF 7.5-10 / F (R)/F (R) BSTF BSTF - 12-14 / F (R)

Refrigerating capacity (W) : 5000, 6000, 7500, 10000, 12000, 14000

Refrigeration power consumption (W) 1860 2230 2780 3800 4650 4860

Heat production (W) 5900 6700 9300 13500 13300 15000

Heating consumption power (W) 1820 2000 2700 3900 4300 4600
(heat pump type)

Air circulation volume (m3/h

Operating temperature: -7℃~43℃

Indoor/outdoor noise dB(A) 42/54 43/55 47/56 48/56 50/60 51/62

Refrigerant name and injection volume KgR22 1.43 R22 2.2 R22 2.3 R22 2.9 R22 3.8 R22 3.9

Weight indoor/outdoor (kg) 38/48 46/70 50/70 50/70 55/70 55/72

Power supply (V/Hz) 220±10%V, 50HZ 208±10%V,60HZ 380%V, 50HZ
