FY300 Crawler Pneumatic Water Well Drilling Rig
US$ 26000 - 28500
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huaxia master
Place of Origin:
China
Model Number:
FY300
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
30 days
Related Products
-
FY400 Crawler Pneumatic Water Well Drilling RigUS$ 35199 - 36000MOQ: 1 Set -
FY600 Crawler Pneumatic Water Well Drilling RigUS$ 35000 - 38000MOQ: 1 Set
-
Supply Large Spj-300 Millstone Household Well Rural Cement Pipe Irrigation Well Drilling Rig Large Caliber Deep Water WellUS$ 9000 - 9900MOQ: 1 Set
-
1.Supply Large Spj-400 Type Grinding Disc Drilling Machine for Household Large-caliber Irrigation Well and 400-meter Deep Water Well Drilling RigUS$ 12000 - 12500MOQ: 1 Set
-
Water Supply 600 Crawler Type Large Aperture Spj-600 Grinding Disc Drilling Machine Automatic Hydraulic Drilling TowerUS$ 26000 - 29000MOQ: 1 Set
Brand Name
Huaxia master
Place of Origin
China
Model Number
FY300
Type
Rotary Drilling Rig
Certification
ISO9001
After-sales Service Provided
Overseas service center available
Warranty
6 months
Weight
8.8t
Dimension(L*W*H)
4350*1850*2750
Power Type
Diesel
Voltage
220V
Usage
Coal
Condition
New
Power(W)
85kw
FY300 crawler pneumatic water well drilling rig
1. The applications of FY300 crawler pneumatic water well drilling rig
· civil engineering drilling
· geothermal drilling,
· drilling with large diameter and deep drilling footage
· It’s fast, flexible and efficient
2. The specifications of FY300 crawler pneumatic water well drilling rig
Model |
FY300 |
|
Gross weight |
t |
8.8 |
Dimension |
mm |
4350*1850*2750 |
Aperture |
mm |
140-325 |
Drilling depth |
m |
300 |
Feed stroke |
mm |
6000 |
Travel speed |
km/h |
2 |
Grade ability |
max. |
30° |
Rising height from ground |
mm |
230 |
Wind pressure |
mpa |
1.7-3.3 |
Air consumption |
m³/min |
23 |
Engine power |
kw |
85 |
Rotary speed |
rpm |
55-115 |
Rotation torque |
n.m |
7200-8500 |
