FY400 Crawler Pneumatic Water Well Drilling Rig

FY400 Crawler Pneumatic Water Well Drilling Rig photo-1
FY400 Crawler Pneumatic Water Well Drilling Rig photo-2
FY400 Crawler Pneumatic Water Well Drilling Rig photo-3
FY400 Crawler Pneumatic Water Well Drilling Rig photo-4
US$ 35199 - 36000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
Huaxia master
Place of Origin:
China
Model Number:
FY400
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
30 days
Brand Name Huaxia master
Place of Origin China
Model Number FY400
Type Rotary Drilling Rig
Certification ISO9001
After-sales Service Provided Overseas service center available
Warranty 6 months
Weight 8.7
Dimension(L*W*H) 5050*2100*2800
Power Type Diesel
Voltage 380V
Usage Coal
Condition New
Power(W) 95kw

FY400 crawler pneumatic water well drilling rig

1.The applications of FY400 crawler pneumatic water well drilling rig

· civil engineering drilling

· geothermal drilling

· drilling with large diameter and deep drilling footage

· It’s fast, flexible and efficient

2. The specifications of FY400 crawler pneumatic water well drilling rig

Model

FY400

Gross weight

T

8.7

Dimension

mm

5050*2100*2800

Aperture

mm

140-325

Drilling depth

m

400

Feed stroke

mm

6000

Travel speed

km/h

2.5

Grade ability

max.

30°

Rising height from ground

mm

250

Wind pressure

mpa

1.7-3.5

Air consumption

m³/min

17-35

Engine power

kw

95

Rotary speed

rpm

45-75

Rotation torque

n.m

8500-10000


Product Tags: pneumatic water well drilling rig , household well drill machine
